- Page 1 2OGG/2OGS 304FICU INDUCTION AND DUAL FUEL RANGE WITH OVEN FOR RESIDENTIAL USE INSTRUCTIONS for installation...
- Page 3 PART I INDUCTION SECTION DUAL FUEL INDUCTION SECTION SECTION...
-
Page 5: Table Of Contents
Pay attention to these symbols present in this manual: DANGER TABLE OF CONTENTS PAGE 1 - Special Warnings You can be killed or seriously injured if you don’t IMMEDIATELY follow instructions. Before Starting Installation Mobile Home Installation 2 - Product Dimensions and Cutout Requirements Anti-Tip Bracket Installation WARNING 3 - Installation Information... -
Page 6: Special Warnings
1 - Special Warnings IMPORTANT INSTRUCTION Special Warnings Please read all instruction before using this appliance. Mobile Home Installation Proper installation is your responsibility. Have a qualified technician install this range. The installation of this appliances must conform to the IMPORTANT Manufactured Home Construction and Safety Standards, Title 24 CFR, Part 3280 (formerly the Federal Standard for Mobile... -
Page 7: Product Dimensions And Cutout Requirements
2 - Product Dimensions and Cutout Requirements DIMENSIONS [29 11/16"] 30” RANGE [29 15/16"] [3/8"] [27 3/16"] [20 5/8"] 1224 [48 3/16"] [29 11/16"] [29 29/32"] 36” RANGE [35 7/8"] [3/8"] [27 3/16"] [20 5/8"] 1224 [48 3/16"] 60" GAS [29 11/16"] [35 29/32"] 60”... - Page 8 2 - Product Dimensions and Cutout Requirements CUTOUT REQUIREMENTS Max. 13” (33) Min. 30” (76.2) To bottom of ventilation hood Min. 18” (45.7) Min. 18” (45.7) 30” 36” RANGE Min. 6” Min. 6” (15.2) (15.2) 3” (7.6) *Suggested location of utilities ELECTRIC 2”...
-
Page 9: Anti-Tip Bracket Installation
2 - Product Dimensions and Cutout Requirements Before moving the range, protect any finished flooring and WARNING secure oven door(s) closed to prevent damage. To verify the anti-tip bracket is installed and engaged: Vent hood Combinations: It is recommended that these ranges be installed in conjunction •... -
Page 10: Installation Information
3 - Installation Information TOOLS WILL YOU NEED WARNING • Excessive Weight Hazard Use two or more people to move and install range. Failure to do so can result in back or other injury. • Cut Hazard Beware of sharp edges. Use the polystyrene ends when carrying the product. -
Page 11: Installation Instructions
4 - Installation Instructions STEP 1 STEP 3 Cut the banding and remove the appliance from the pallet by a Move the range indoors before installing the legs, position the hand-truck inserting the blade under the foam base. appliance near its final location as the legs are not suitable for moving the appliance over long distances. - Page 12 4 - Installation Instructions STEP 5 STEP 6 Pull out the hand-truck, tilt the range laterally and insert the After the electrical and gas connections (see both paragraphs second pair of legs. Remove the base for instructions) measure the four corners in cutout area to verify if flooring is level.
-
Page 13: Electrical Supply
5 - Electrical supply Before installing the oven have a qualified electrician verify WARNING that your home is provided with adequate electrical service and that the addition of the oven will not overload the branch circuit on which it is to be installed. Risk of Electric Shock, frame grounded to neutral of Be sure your appliance is properly installed and grounded appliance through a link... - Page 14 WARNING ELECTRICAL SHOCK HAZARD • The electrical power to the appliance branch circuit must be shut off while line connections are being made. • Do not use an extension cord with this appliance. • Electrical ground is required on this appliance. •...
-
Page 15: Electrical Connections
6 - Electrical connections LOCATION OF ELECTRICAL CONNECTION CAUTION Do not repair or replace any part of the appliance unless specifically recommended in the manual. All other servicing should be done by a qualified technician. This may reduce the risk of personal injury and damage to the appliance. Never modify or alter the construction of the appliance by removing panels, wire covers, screws, or any other part of the product. -
Page 16: 4-Wire Connection
6 - Electrical connections ELECTRICAL CONNECTION OPTIONS IF YOUR HOME HAS AND YOU WILL BE CONNECTION IF YOUR HOME HAS AND YOU WILL BE CONNECTION CONNECTING TO: TYPE: CONNECTING TO: TYPE: 4-wire receptacle 3-wire receptacle A UL listed, 250- A UL listed, 250- (NEMA type 14-50R) (NEMA type 10-50R) volt minimum,... -
Page 17: Direct Electrical Connection To The Circuit Breaker, Fuse Box Or Junction Box
6 - Electrical connections “36” INDUCTION RANGE 4-WIRE CONNECTION “36” INDUCTION RANGE 3-WIRE CONNECTION A. Green A. Red B. Red B. White C. White C. Black D. Black Direct Electrical Connection to the Circuit Breaker, Fuse Box or Junction Box If the appliance is connected directly to the circuit breaker, fuse box or junction box, use flexible, armored or non metallic sheathed copper cable (with grounding wire). -
Page 18: Final Checklist
7 - Final checklist CONNECTING TO 208 VOLT CIRCUIT To prevent improper connections leading to damage of This option is provided for areas where standard 240 Volt electrical components and so voiding the warranty, the service is not available. This option must be accessed with the following steps must be performed: appliance connected to power source, and using the following sequence:... - Page 21 PART II DUAL FUEL SECTION DUAL FUEL INDUCTION SECTION SECTION...
- Page 23 Pay attention to these symbols present in this manual: DANGER TABLE OF CONTENTS PAGE 1 - Special Warnings You can be killed or seriously injured if you don’t IMMEDIATELY follow instructions. Before Starting Installation Mobile Home Installation Recreational Park Trailers 2 - Product Dimensions and Cutout Requirements Anti-Tip Bracket Installation WARNING...
-
Page 24: Special Warnings
1 - Special Warnings IMPORTANT INSTRUCTION Please read all instructions before using this appliance. Proper installation is your responsibility. Have a qualified Copies of the standards listed may be obtained from: technician install this range. National Fire Protection Association One Batterymarch Park Quincy, Massachusetts 02269 IMPORTANT *** CSA International 8501 East Pleasant Valley Rd. -
Page 25: Product Dimensions And Cutout Requirements
2 - Product Dimensions and Cutout Requirements DIMENSIONS [29 11/16"] 30” RANGE [29 15/16"] [3/8"] [27 3/16"] [20 5/8"] 1224 [48 3/16"] [29 11/16"] [29 29/32"] 36” RANGE [35 7/8"] [3/8"] [27 3/16"] [20 5/8"] 1224 [48 3/16"] [29 11/16"] [35 29/32"] 48”... - Page 26 2 - Product Dimensions and Cutout Requirements CUTOUT REQUIREMENTS Max. 13” (33) Min. 30” (76.2) Min. 48” (122) To bottom of Minimum ventilation hood to Combustibles Min. 18” (45.7) Min. 18” (45.7) 30” 36” 48” RANGE Min. 6” Min. 6” (15.2) (15.2) 3”...
-
Page 27: Anti-Tip Bracket Installation
2 - Product Dimensions and Cutout Requirements Before moving the range, protect any finished flooring and WARNING secure oven door(s) closed to prevent damage. To verify the anti-tip bracket is installed and engaged: Vent hood Combinations: It is recommended that these ranges be installed in conjunction •... -
Page 28: Installation Information
3 - Installation Information TOOLS WILL YOU NEED WARNING • Excessive Weight Hazard Use two or more people to move and install range. Failure to do so can result in back or other injury. • Cut Hazard Beware of sharp edges. Use the polystyrene ends when carrying the product. -
Page 29: Installation Instructions
4 - Installation Instructions STEP 1 STEP 3/4 (For 48” range only) Cut the banding (1) and remove the Installation Instructions Slide the range back just enough to allow the rear feet to be from the top of range and read them carefully before you installed. - Page 30 4 - Installation Instructions STEP 5 STEP 8 Slide back more and tilt back (9), putting the rear legs on the After completing the electrical and gas connections (see floor and then mount the front legs while in this angled position included instructions) measure the four corners in cutout area supported by the rear legs and the skid.
- Page 31 4 - Installation Instructions STEP 10 Hook tabs on bottom of toekick into slots on either side of the frame and rotate up until the magnets at the top of toekick make contact and hold it in place securely...
-
Page 32: Gas Requirement
5 - Gas Requirement QUALIFIED SERVICE MAN OR GAS APPLIANCE INSTALLER If at any time the appliance is to be used with a different type MUST MAKE THE GAS SUPPLY CONNECTION. of gas, all the conversion adjustments must be made by a qualified technician before attempting to operate the range Leak testing of the appliance shall be conducted by the installer with that gas. -
Page 33: Pressure Testing
5 - Gas Requirement Pressure Testing The appliance must be isolated from the gas supply piping IMPORTANT system by closing its individual manual shut-off valve during any pressure testing of the gas supply piping system at test NEVER REUSE OLD CONNECTORS WHEN INSTALLING THIS pressures equal to or less than 1/2 PSIG (3.5 kPa). -
Page 34: Gas Connection
5 - Gas Requirement Gas Connection • Thread the appliances pressure regulator with 1/2” male Unless prohibited by local codes or ordinances, a new A.G.A. end connection both supplied with this appliance. - Certified, flexible metal appliance connector may be used to connect this appliance to its gas supply. -
Page 35: Conversion For Lp Or Ng Gas
6 - Conversion for LP or NG Gas Converting Appliance for Use with LP Gas EXPLODED VIEW OF BURNER WARNING Conversion is to be performed by an AUTHORIZED SERVICER (or other qualified agency) in accordance with the manufacturer’s instructions and all codes and requirements of the authority having jurisdiction. -
Page 36: Converting Appliances For Use With Ng Gas
6 - Conversion for LP or NG Gas Pressure regulator conversion The appliances is designed for use with NG gas or LP gas. The EXPLODED VIEW OF BURNER gas pressure regulator is supplied. It must be installed in the gas supply line ahead of the manifold entrance. It is pre-set for use with the gas as indicated on the appliance label supplied with the appliance. -
Page 37: Injectors Position
6 - Conversion for LP or NG Gas INJECTORS POSITION NG- DUAL FLAME RING 30”/60” SIMMER MAIN FLAME 180 SIMMER MAIN FLAME 192 NG- DUAL FLAME RING 36” SIMMER MAIN FLAME 180 SIMMER MAIN FLAME 192 NG- DUAL FLAME RING & GRIDDLE 48” SIMMER MAIN FLAME 180 MAIN FLAME 155... - Page 38 6 - Conversion for LP or NG Gas INJECTORS POSITION LP- DUAL FLAME RING 30”/60” SIMMER MAIN FLAME 105 LP- DUAL FLAME RING 36” SIMMER MAIN FLAME 105 LP- DUAL FLAME RING & GRIDDLE 48” SIMMER MAIN FLAME 98 MAIN FLAME 105...
-
Page 39: Low Flame Adjustment
6 - Conversion for LP or NG Gas Low Flame Adjustment This appliance is shipped from the factory with low and DANGER medium flame settings adjusted. If further adjustment is necessary, proceed as follows: Lighting gas burners with a match is dangerous. You should match light the burners only in an emergency. -
Page 40: Electronic Burner Ignition
6 - Conversion for LP or NG Gas Proper adjustment will produce a stable, steady blue flame of minimum size. The final adjustment should be checked by turning the knob from high to low several times without extinguishing the flame. This adjustment, at low setting, will automatically provide the proper flame size at medium setting. -
Page 41: Electrical Supply
7 - Electrical supply Before installing the oven have a qualified electrician verify Grounding through the neutral conductor is prohibited for new that your home is provided with adequate electrical service branch-circuit installations (1996 NEC); mobile homes; and and that the addition of the oven will not overload the branch recreational vehicles, or in an area where local codes prohibit circuit on which it is to be installed. - Page 42 8 - Electrical connections LOCATION OF ELECTRICAL CONNECTION CAUTION Do not repair or replace any part of the appliance unless specifically recommended in the manual. All other servicing should be done by a qualified technician. This may reduce the risk of personal injury and damage to the appliance. Never modify or alter the construction of the appliance by removing panels, wire covers, screws, or any other part of the product.
-
Page 43: Electrical Connections
8 - Electrical connections ELECTRICAL CONNECTION OPTIONS IF YOUR HOME HAS AND YOU WILL CONNECTION IF YOUR HOME HAS AND YOU WILL CONNECTION BE CONNECTING TYPE: BE CONNECTING TYPE: 4-wire receptacle 3-wire receptacle A UL listed, 250- A UL listed, 250- (NEMA type 14-50R) (NEMA type 10-50R) volt minimum,... -
Page 44: Direct Electrical Connection To The Circuit Breaker, Fuse Box Or Junction Box
8 - Electrical connections Direct Electrical Connection to the Circuit Breaker, Fuse Box or Junction Box If the appliance is connected directly to the circuit breaker, fuse box or junction box, use flexible, armored or non metallic sheathed copper cable (with grounding wire). 3-WIRE BRANCH CIRCUIT (for US only) 4-WIRE BRANCH CIRCUIT (for US only) Refer to Figure A:... -
Page 45: Final Checklist
9 - Final checklist CONNECTING TO 208 VOLT CIRCUIT This option is provided for areas where standard 240 Volt To prevent improper connections leading to damage of service is not available. This option must be accessed with the electrical components and so voiding the warranty, the appliance connected to power source, and using the following following steps must be performed: sequence:... - Page 48 V 2.5 - 7.18 Via Della Torricella 29, Antella, Bagno a Ripoli 50012 Florence - Italy Tel. +39 055 65 60 3324 / +39 055 62 18 07 Fax. +39 055 62 06 70 officinegullo.com | info@officinegullo.com...
