  • Page 2 ___________________ Preface ___________________ Documentation guide ___________________ SIMATIC Product overview ___________________ Wiring S7-1500/ET 200MP Digital output module ___________________ DQ 16x230VAC/1A ST Triac Parameters/address space (6ES7522-5FH00-0AB0) ___________________ Diagnostic alarms Manual ___________________ Technical specifications ___________________ Dimensional drawing ___________________ Parameter data records 09/2016 A5E34934069-AB...
  • Page 3 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.
  • Page 4: Preface

    Internet as of 09/2016. Conventions CPU: The term "CPU" is used in this manual both for the CPUs of the S7-1500 automation system and for interface modules of the ET 200MP distributed I/O system. STEP 7: In this documentation, "STEP 7" is used as a synonym for all versions of the configuration and programming software "STEP 7 (TIA Portal)".
  • Page 5 In order to protect plants, systems, machines and networks against cyber threats, it is necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial security concept. Siemens’ products and solutions only form one element of such a concept. Customer is responsible to prevent unauthorized access to its plants, systems, machines and networks.
  • Page 6: Table Of Contents

    Table of contents Preface ..............................4 Documentation guide ..........................7 Product overview ..........................11 Properties ..........................11 Wiring ..............................13 Parameters/address space ........................15 Parameters ..........................15 Declaration of parameters ...................... 15 Address space ........................16 Diagnostic alarms ..........................21 Status and error displays .......................
  • Page 7: Documentation Guide

    Documentation guide The documentation for the SIMATIC S7-1500 automation system, the CPU 1516pro-2 PN based on SIMATIC S7-1500 and the SIMATIC ET 200MP distributed I/O system is arranged into three areas. This arrangement enables you to access the specific content you require.
  • Page 8 Documentation guide General information The function manuals contain detailed descriptions on general topics regarding the SIMATIC S7-1500 and ET 200MP systems, e.g. diagnostics, communication, motion control, Web server, OPC UA. You can download the documentation free of charge from the Internet (http://w3.siemens.com/mcms/industrial-automation-systems-simatic/en/manual-...
  • Page 9 ● Manuals, characteristics, operating manuals, certificates ● Product master data You can find "mySupport" - CAx data on the Internet (http://support.industry.siemens.com/my/ww/en/CAxOnline). Application examples The application examples support you with various tools and examples for solving your automation tasks. Solutions are shown in interplay with multiple components in the system - separated from the focus on individual products.
  • Page 10 You can find the SIMATIC Automation Tool on the Internet (https://support.industry.siemens.com/cs/ww/en/view/98161300). PRONETA With SIEMENS PRONETA (PROFINET network analysis), you analyze the PROFINET network during commissioning. PRONETA features two core functions: ● The topology overview independently scans PROFINET and all connected components.
  • Page 11: Product Overview

    Product overview Properties Article number 6ES7522-5FH00-0AB0 View of the module Figure 2-1 View of the DQ 16x230VAC/1A ST module Properties The module has the following technical properties: ● 16 digital outputs (Triac) ● Rated output voltage 120 V/230 V AC ●...
  • Page 12 Other components The following component can be ordered separately: Front connectors, including potential jumpers and cable ties For more information on accessories, refer to the S7-1500, ET 200MP system manual (https://support.industry.siemens.com/cs/ww/en/view/59191792). Digital output module DQ 16x230VAC/1A ST Triac (6ES7522-5FH00-0AB0) Manual, 09/2016, A5E34934069-AB...
  • Page 13: Wiring

    This section contains the block diagram of the module and outlines various wiring options. You can find information on wiring the front connector, creating a cable shield, etc. in the Wiring section of the S7-1500, ET 200MP system manual (https://support.industry.siemens.com/cs/ww/en/view/59191792).
  • Page 14 Wiring Wiring and block diagram The example in the following figure shows the terminal assignment and the assignment of the channels. The individual channels are connected with a TRIAC (Triode for Alternating Current). ① TRIAC 16x Channel or channel status LED (green) ②...
  • Page 15: Parameters/address Space

    The following configurations are possible: ● Central operation with a S7-1500 CPU ● Distributed operation on PROFINET IO in an ET 200MP system ● Distributed operation on PROFIBUS DP in an ET 200MP system For parameter assignment in the user program, the parameters are transferred to the module using the WRREC instruction (reconfiguration in RUN) and data records;...
  • Page 16: Address Space

    Parameters/address space 4.3 Address space Address space The module can be configured differently in STEP 7; see following table. Depending on the configuration, additional/different addresses are assigned in the process image output/input. Configuration options of DQ 16x230VAC/1A ST You can configure the module with STEP 7 or with a GSD file. When you configure the module by means of the GSD file, the configurations are available under different short designations/module names.
  • Page 17 Parameters/address space 4.3 Address space Address space for configuration as 16-channel DQ 16x230VAC/1A ST The figure below shows the address space allocation for the configuration as 16-channel module. You can freely assign the start address for the module. The addresses of the channels are derived from the start address.
  • Page 18 Parameters/address space 4.3 Address space Address space for configuration as 1 x 16-channel DQ 16x230VAC/1A ST MSO For the configuration as a 1 x 16-channel module (module-internal Shared Output, MSO), channels 0 to 15 of the module are copied to multiple submodules. Channels 0 to 15 are then available with identical values in various submodules.
  • Page 19 Parameters/address space 4.3 Address space The following figure shows the assignment of the address space for submodules 1 and 2 and the value status. Figure 4-3 Address space for configuration as 1 x 16-channel DQ 16x230VAC/1A ST MSO with value status Digital output module DQ 16x230VAC/1A ST Triac (6ES7522-5FH00-0AB0) Manual, 09/2016, A5E34934069-AB...
  • Page 20 Reference You will find information on the module-internal shared input/shared output (MSI/MSO) function in the function manual PROFINET with STEP 7 V13 (https://support.industry.siemens.com/cs/ww/en/view/49948856) in the section Module- internal shared input/shared output (MSI/MSO). Digital output module DQ 16x230VAC/1A ST Triac (6ES7522-5FH00-0AB0)
  • Page 21: Diagnostic Alarms

    Diagnostic alarms Status and error displays LED displays The figure below shows the LED displays (status and error displays) of DQ 16x230VAC/1A ST. Figure 5-1 LED displays of the module DQ 16x230VAC/1A ST Digital output module DQ 16x230VAC/1A ST Triac (6ES7522-5FH00-0AB0) Manual, 09/2016, A5E34934069-AB...
  • Page 22 Diagnostic alarms 5.1 Status and error displays Meaning of the LED displays The following table explains the meaning of the status and error displays. RUN and ERROR LED Table 5- 1 RUN and ERROR status and error displays Meaning Solution ERROR Voltage missing or too low at backplane bus Switch on the CPU and/or the system pow-...
  • Page 23: Technical Specifications

    Technical specifications Technical specifications of the DQ 16x230VAC/1A ST 6ES7522-5FH00-0AB0 General information Product type designation DQ 16x230VAC/1A ST (Triac) Hardware functional status FS01 Firmware version V1.0.0 FW update possible • Product function I&M data Yes; I&M0 to I&M3 Engineering with STEP 7 TIA Portal can be configured/integrated V13 SP1 / - as of version...
  • Page 24 Technical specifications 6ES7522-5FH00-0AB0 Output voltage For signal "1", min. L1 (-1.5 V) at maximum output current; L1 (-8.5 V) at minimum output current Output current For signal "1" rated value For signal "1" permitted range, min. 10 mA For signal "1" permitted range, max. 15 A;...
  • Page 25 Technical specifications 6ES7522-5FH00-0AB0 Diagnostics indicator LED RUN LED Yes; green LED ERROR LED Yes; red LED Monitoring of supply voltage (PWR LED) Channel status display Yes; green LED For channel diagnostics For module diagnostics Yes; red LED Electrical isolation Electrical isolation of channels Between the channels Between the channels, in groups of Between the channels and backplane bus...
  • Page 26 Technical specifications Power reduction (derating) to aggregate current of outputs (per module) The following graphs show the loading capacity of the outputs in relation to the mounting position of the S71500 automation system/ET 200MP distributed I/O system and the ambient temperature.
  • Page 27: Dimensional Drawing

    Dimensional drawing The dimension drawing of the module on the mounting rail, as well as a dimension drawing with open front cover, are provided in the appendix. Always observe the specified dimensions for installation in cabinets, control rooms, etc. Figure A-1 Dimension drawing of the DQ 16x230VAC/1A ST module Digital output module DQ 16x230VAC/1A ST Triac (6ES7522-5FH00-0AB0) Manual, 09/2016, A5E34934069-AB...
  • Page 28 Dimensional drawing Figure A-2 Dimension drawing of the DQ 16x230VAC/1A ST module, side view with open front cover Digital output module DQ 16x230VAC/1A ST Triac (6ES7522-5FH00-0AB0) Manual, 09/2016, A5E34934069-AB...
  • Page 29: Parameter Data Records

    0 and 1 are not read back. You get the diagnostics data records 0 and 1 for the read back parameter data records 0 and 1. You can find more information in the Interrupts section of the PROFIBUS DP interface module device manual on the Internet (http://support.automation.siemens.com/WW/view/en/78324181). Digital output module DQ 16x230VAC/1A ST Triac (6ES7522-5FH00-0AB0) Manual, 09/2016, A5E34934069-AB...
  • Page 30 Parameter data records B.1 Parameter assignment and structure of the parameter data records Assignment of data record and channel For the configuration as a 1 x 16-channel module, the parameters are located in data records 64 to 79 and are assigned as follows: ●...
