General Description

1
2
3
12
11
10
9
1 Pusher
5 Anti-drip Tap
2 Cover
6 Peel Bucket
3 Locking Handle
7 Coaster
4 Stainless Steel Tank
8 Coaster Inox Trim
4
5
6
8
7
9 Filter Driver Nut
10 Filter Driver
11 Filter
12 Grating Disk
Preparation
Setting up the juice extractor:
1
Remove the packaging and place the juice extractor on a flat surface.
2
Connect the supplied cord to the appliance and plug into a standardised
earthed socket. Fig.1
3
Place the peel bucket as shown in Fig.2. To keep the peel bucket from getting
dirty, you can line it with a bin bag, leaving the top of the bag hanging over
the edges of the container.
Check that all parts affected by the safety cut-offs are correctly positioned
4
otherwise the safety cut-offs will stop the appliance from working.
!
Remember: Given that the diameter of the fruit feeding
tube is 75 mm, larger fruits should be cut up into smaller
pieces. When the pieces of fruit are very much smaller than
the conduct's diameter, you may process several together.
EN
ES
75mm
13
13
