ZUMEX MULTIFRUIT User Manual page 11

Cleaning
Zumex recommends cleaning the machine at least once or twice a day, depending on
how much it is used in order to maintain optimal food hygiene conditions.
The following are the steps for correctly cleaning the juice extractor:
Put the rear switch on "0" and disconnect the machine from the power supply,
1
by pulling the plug (do no pull the cable).
2 Remove the handle lifting it up from the front.
Remove the cover lifting it upwards and separate it from the peel bucket.
3
Dismantle the anti-drip tap and coaster.
4
Dismantle the grater-filter and the stainless steel tank assembly, by pulling the
5
bucket upwards, following which they should come apart easily.
Attention! Handle the grater-filter assembly carefully. Do not touch the
!
sharp points of the grater as they could cut you.
1 2
4 5
EN ES
3
!
17 17
