Page 3: Hull Identification Number
This document discloses subject matter in which Bayliner has proprietary rights. The information and design disclosed herein were originated by and are the prop- erty of Bayliner. Neither receipt nor possession thereof confers or transfers any right to reproduce, copy, alter or disclose the document or any part thereof, any information contained therein, or to construct boats or any item from it, except by written permission from or written agreement with Bayliner. -
Page 4: Table Of Contents
CONTENTS Chapter 1: Welcome Aboard! Chapter 2: Features & Systems Dimensions and Tank Capacities Hull Exterior Hardware & Drains Layout View Quick Oil Drain System Dealer Service Deck Hardware and Accessories Warranty Information Helm Layout (Command Bridge) Boating Experience Electrical Systems Engine &... - Page 5 Propulsion Chapter 3: Electrical Routings 22 Engine Hull Wire Harness Routings Fuel System Deck Wire Harness Routings 22 Fuel Fill and Vent: Battery Cable Routings 22 Fuel Filters: 23 Anti-siphon Valve: Engine Room Ventilation System Chapter 4: Wiring Diagrams Trim Tabs AC Electrical System Single Dockside Bilge Pumps AC Electrical System Dual Dockside...
- Page 6 Hazard Boxes & Symbols The hazard boxes and symbols shown below are used throughout this Supplement to call attention to potentially dan- gerous situations which could lead to either personal injury or product damage. Read ALL warnings carefully and follow all safety instructions. DANGER! This box alerts you to immediate hazards which WILL cause severe personal injury or death if the warning is ignored.
-
Page 7: Chapter 1: Welcome Aboard
• Buy replacement parts from any authorized Bayliner dealer. Warranty Information • Bayliner offers a Limited Warranty on each new Bayliner purchased through an authorized Bayliner dealer. • A copy of the Limited Warranty was included in your owner’s packet. -
Page 8: Boating Experience
Chapter 1: Welcome Aboard! 2858 Classic Cruiser • Owner’s Manual Supplement Boating Experience If this is your first boat or if you are changing to a type of boat you are not familiar with, for your own comfort and safety, obtain handling and operating experience before assuming command of the boat. -
Page 9: Safety Standards
2858 Classic Cruiser • Owner’s Manual Supplement Chapter 1: Welcome Aboard! Safety Standards DANGER! FALLING and ROTATING PROPELLER HAZARD! NEVER allow anyone to ride on parts of the boat not designed for such use. • Sitting on seat backs, lounging on the forward deck, bow riding, gunwale riding or occupying the transom platform while underway is especially hazardous and will cause personal injury or death. -
Page 10: Structural Limitations
Chapter 1: Welcome Aboard! 2858 Classic Cruiser • Owner’s Manual Supplement Structural Limitations The transom platform and bow platform are designed to be lightweight for proper boat balance. The load limit for these platforms is 30 pounds per square foot, evenly distributed. -
Page 11: Carbon Monoxide (Co)
2858 Classic Cruiser • Owner’s Manual Supplement Chapter 1: Welcome Aboard! Carbon Monoxide (CO) DANGER! • Carbon monoxide gas (CO) is colorless, odorless, tasteless, and extremely dangerous. • All engines, generators, and fuel burning appliances produce CO as exhaust. • Prolonged exposure to low concentrations or very quick exposure to high concentrations will cause BRAIN DAMAGE or DEATH. -
Page 12: Where And How Co Can Accumulate
Chapter 1: Welcome Aboard! 2858 Classic Cruiser • Owner’s Manual Supplement Where and How CO Can Accumulate Stationary Conditions That Increase CO Accumulations Include: A. Using engine, generator, or other fuel burn- ing device when boat is moored in a confined space. -
Page 13: Trip Checklist
2858 Classic Cruiser • Owner’s Manual Supplement Chapter 1: Welcome Aboard! Trip Checklist ❏ Make sure you know where the exhaust outlets are located on your boat. ❏ Educate all passengers about the symptoms of CO poisoning and where CO may accumulate. -
Page 14: More Information
Chapter 1: Welcome Aboard! 2858 Classic Cruiser • Owner’s Manual Supplement More Information For more information about how you can prevent carbon monoxide poisoning on recreational boats and other ways to boat more safely, contact: United States Coast Guard National Marine Manufacturers American Boat &... -
Page 15: Boat Lifting
2858 Classic Cruiser • Owner’s Manual Supplement Chapter 1: Welcome Aboard! Boat Lifting WARNING! PERSONAL INJURY and /or PRODUCT OR PROPERTY DAMAGE HAZARD! • Lifting slings may slip on the hull. • Avoid serious injury or death by securing the lifting slings together before lifting. -
Page 16: Chapter 2: Features & Systems
2858 Classic Cruiser • Owner’s Manual Supplement Chapter 2: Features & Systems Hull Exterior Hardware & Drains WATER TANK GALLEY SINK VENT DRAIN STARBOARD SIDE VIEW ANCHOR WELL DRAIN ANCHOR LOCKER DRAIN AFT BILGE PUMP DRAIN FWD BILGE HEAD SINK... -
Page 17: Quick Oil Drain System
2858 Classic Cruiser • Owner’s Manual Supplement Chapter 2: Features & Systems Quick Oil Drain System QUICK OIL DRAIN SYSTEM TRANSOM OIL DRAIN HOSE OIL DRAIN PLUG ENGINE OIL PAN GARBOARD DRAIN PLUG DRAW CORD BILGE GARBOARD DRAIN To drain the engine oil: 1. -
Page 18: Deck Hardware And Accessories
Chapter 2: Features & Systems 2858 Classic Cruiser • Owner’s Manual Supplement Deck Hardware and Accessories ROPE LOCKER WINDLASS SWITCHES ANCHOR WINDLASS (OPTION) WASTE PUMP OUT FITTING AFT DECK STORAGE AREA DECK CLEAT (TYPICAL) WATER FILL FITTING SHORE POWER CONNECTIONS... -
Page 19: Helm Layout (Command Bridge)
2858 Classic Cruiser • Owner’s Manual Supplement Chapter 2: Features & Systems H e lm L a y ou t (C o m m a n d B ri d g e ) VIEW OF COMMAND BRIDGE HELM LOOKING FORWARD... -
Page 20: Electrical Systems
Chapter 2: Features & Systems 2858 Classic Cruiser • Owner’s Manual Supplement Electrical Systems DAN GER! EXTREME FIRE, SHOCK & EXPLOSION HAZARD! • To minimize the risks of fire and explosion, NEVER install knife switches or other arcing devices in the fuel compartments. -
Page 21: Dc Electrical System
2858 Classic Cruiser • Owner’s Manual Supplement Chapter 2: Features & Systems DC Electrical System Your boat is equipped with a 12 volt DC (direct current) system. The DC breaker panel is located at the helm, just below the ignition panel. -
Page 22: Battery Switch
Chapter 2: Features & Systems 2858 Classic Cruiser • Owner’s Manual Supplement Battery Switch The battery switch (located in the cockpit storage locker) has four (4) positions. POSITION "BOTH" SELECTS BOTH BATTERIES BATTERY SWITCH (IN OFF POSITION) POSITION "1" SELECTS BATTERY "1"... -
Page 23: Shore Power/110 Volt Ac System
2858 Classic Cruiser • Owner’s Manual Supplement Chapter 2: Features & Systems Shore Power/110 Volt AC System DANGER! FIRE, EXPLOSION & SHOCK HAZARD! • DO NOT alter shore power connectors and use only compatible connectors. • Before plugging in or unplugging the shore power cord to your boat, make sure all breakers and switches on the AC master panel are turned Off. -
Page 24: Connecting To Shore Power
Chapter 2: Features & Systems 2858 Classic Cruiser • Owner’s Manual Supplement • Standard 110 volt AC systems feature one, 110V/30 amp, shore power receptacle. • If your boat is equipped with an optional air conditioning system, a second (dual) 30 amp inlet has been installed. -
Page 25: Navigation & Communication Equipment
2858 Classic Cruiser • Owner’s Manual Supplement Chapter 2: Features & Systems Navigation & Communication Equipment The owner’s packet contains operation manuals for all navigation & communication equipment installed on your boat. Thoroughly read and understand these manuals before using these systems. Additionally, read the warnings below carefully and follow all safety recommendations. -
Page 26: Lighting
Chapter 2: Features & Systems 2858 Classic Cruiser • Owner’s Manual Supplement Lighting Navigation and Interior Lights Read and understand the navigation light section of the Cruiser & Yacht Owner’s Manual. The navigation and interior lights installed on your boat are of top quality, but they may fail occasionally for a variety of reasons: 1. -
Page 27: Alcohol/Electric Stove
2858 Classic Cruiser • Owner’s Manual Supplement Chapter 2: Features & Systems Alcohol/Electric Stove DANGER! CARBON MONOXIDE POISONING HAZARD! • The alcohol stove is a source of dangerous carbon monoxide gas (CO). • BEFORE using the alcohol stove, open doors and windows to make sure there is enough fresh air for ventilation. -
Page 28: Propulsion
Chapter 2: Features & Systems 2858 Classic Cruiser • Owner’s Manual Supplement Propulsion Engine The engine compartment can be accessed through the cockpit engine hatch. The owner’s packet contains detailed engine operation and maintenance manuals. Read and understand these manuals before operating or performing maintenance to the engine. -
Page 29: Anti-Siphon Valve
2858 Classic Cruiser • Owner’s Manual Supplement Chapter 2: Features & Systems Anti-siphon Valve: Your boat is equipped with an anti-siphon valve, which is an integral part of the barb fitting on the fuel tank in which the neoprene fuel line attaches. The valve is spring loaded and is opened by fuel pump vacuum. These valves will prevent fuel from siphoning from the tank in the event of a fuel line rupture. -
Page 30: Trim Tabs
Chapter 2: Features & Systems 2858 Classic Cruiser • Owner’s Manual Supplement Trim Tabs VIEW OF THE HELM TRIM TAB SWITCH TRIM TAB COMPONENTS TRANSOM TRIM TAB (TYPICAL) WARNING! LOSS OF CONTROL HAZARD! Improper use of trim tabs will cause loss of control! •... -
Page 31: Bilge Pumps
2858 Classic Cruiser • Owner’s Manual Supplement Chapter 2: Features & Systems Bilge Pumps THE AFT BILGE PUMP IS THE FORWARD BILGE PUMP IS LOCATED UNDER THE ENGINE LOCATED UNDER THE CABIN FLOOR AFT BILGE PUMP FWD BILGE PUMP & FLOAT SWITCH &... -
Page 32: Autofloat Switches
Chapter 2: Features & Systems 2858 Classic Cruiser • Owner’s Manual Supplement Bilge Pump Testing Bilge pumps are critical to the safety of your boat. Check the bilge pumps often to make sure they are working. Individually test each pump as follows: BILGE PUMP 1. -
Page 33: Freshwater System
2858 Classic Cruiser • Owner’s Manual Supplement Chapter 2: Features & Systems Freshwater System PUSH TO RESET CIRCUIT BREAKER WATER LINE ROUTING (UNDER METAL COVER) FROM WATER TANK WATER HEATER FITTING FOR COLD WATER LINE PUMP WATER LINE FITTING FOR... -
Page 34: Freshwater System Winterization
Chapter 2: Features & Systems 2858 Classic Cruiser • Owner’s Manual Supplement Freshwater System Winterization CAUTION! WATER SYSTEM DAMAGE HAZARD! Never blow compressed air through the water system when all of the faucets are Closed. 1. Turn On the water system switch. -
Page 35: Water Heater
2858 Classic Cruiser • Owner’s Manual Supplement Chapter 2: Features & Systems Water Heater WARNING! HOT HAZARD! Water heated by the water heater can reach temperatures hot enough to scald the skin. CAUTION WATER HEATER DAMAGE HAZARD! • DO NOT turn On the water heater electrical circuit on the AC panel until the water heater tank is COMPLETELY filled with water. -
Page 36: Sink & Shower Drain Systems
Chapter 2: Features & Systems 2858 Classic Cruiser • Owner’s Manual Supplement Sink & Shower Drain Systems Gray water (water from sinks and showers) above the waterline is gravity drained overboard, while gray water below the waterline is pumped overboard using a sump pump. -
Page 37: Seawater Strainers
2858 Classic Cruiser • Owner’s Manual Supplement Chapter 2: Features & Systems Seawater Strainers CAUTION! FLOODING HAZARD! • The intake seacock that sends seawater to the strainer must be Closed before disassembling the seawater strainer to prevent the boat from taking on water through the seawater strainer assembly. -
Page 38: Marine Head With Holding Tank
Chapter 2: Features & Systems 2858 Classic Cruiser • Owner’s Manual Supplement Marine Head with Holding Tank NOTICE Check with local authorities for regulations regarding the legal use of marine head systems. MACERATOR SYSTEM (OPTION) HEAD PICKUP LOCATED MARINE HEAD SYSTEM... - Page 39 2858 Classic Cruiser • Owner’s Manual Supplement Chapter 2: Features & Systems Operating the manual flush marine head: 1. Open the head’s seawater intake valve (seacock). 2. Before using the head, pump enough water into the bowl to wet the sides.
-
Page 40: Air Conditioning System (Option)
Chapter 2: Features & Systems 2858 Classic Cruiser • Owner’s Manual Supplement Air Conditioning System (Option) DANGER! CARBON MONOXIDE POISONING HAZARD! Dangerous carbon monoxide gas (CO) can be brought into the boat through the air conditioning system. CAUTION SYSTEM DAMAGE HAZARD! The air conditioning system’s seacock must be Opened before turning On the air conditioner... -
Page 41: Chapter 3: Electrical Routings
2858 Classic Cruiser • Owner’s Manual Supplement Chapter 3: Electrical Routings Hull Wire Harness Routings TO BATTERY AFT BERTH READING TRIM LIGHT PUMP MACERATOR FWD BILGE PUMP BATTERY CHARGER HEAD PICKUP GROUND FUEL TANK STEP TRIM TABS SENDER LIGHT ENGINE... -
Page 42: Deck Wire Harness Routings
Chapter 3: Electrical Routings 2858 Classic Cruiser • Owner’s Manual Supplement Deck Wire Harness Routings NOTE: VIEW IS OF UNDERSIDE OF DECK LIGHT TO WINDLASS, RELAY & DECK SWITCHES HORN V-BERTH OVERHEAD LIGHT PORT WIPER WIPERS STBD SPEAKER WIRES HALL... -
Page 43: Battery Cable Routings
2858 Classic Cruiser • Owner’s Manual Supplement Chapter 3: Electrical Routings Battery Cable Routings POSITIVE BATTERY CABLE ROUTINGS TO BATTERY SWITCH IN TRANSOM STORAGE JUMPER CABLE TO STARTER SOLENOID POSITIVE ON ENGINE CABLES BATTERIES NEGATIVE BATTERY CABLE ROUTINGS GROUND NEGATIVE CABLES... -
Page 44: Chapter 4: Wiring Diagrams
2858 Classic Cruiser • Owner’s Manual Supplement Chapter 4: Wiring Diagrams AC Electrical System Single Dockside... -
Page 45: Ac Electrical System Dual Dockside
2858 Classic Cruiser • Owner’s Manual Supplement Chapter 4: Wiring Diagrams AC Electrical System Dual Dockside... -
Page 46: Gas Engine Electrical System
Chapter 4: Wiring Diagrams 2858 Classic Cruiser • Owner’s Manual Supplement Gas Engine Electrical System... -
Page 47: Diesel Engine Electrical System
2858 Classic Cruiser • Owner’s Manual Supplement Chapter 4: Wiring Diagrams Diesel Engine Electrical System... -
Page 48: Important Records
2858 Classic Cruiser • Owner’s Manual Supplement Important Records Selling Dealer Key Numbers Name Of Dealership Ignition Other Address Electronics Phone/FAX/E-mail Manufacturer Model Name/Number Sales Manager Serial Number Service Manager Manufacturer Model Name/Number Engine Serial Number Manufacturer Model Name/Number Engine Serial Number... -
Page 49: Float Plan
2858 Classic Cruiser • Owner’s Manual Supplement Float Plan Before going boating, fill out a copy of this float plan (or similar) and leave it with a reliable person whom you can depend on to contact the Coast Guard or other rescue organization, if you do not return as scheduled. - Page 50 Float Plan 2858 Classic Cruiser • Owner’s Manual Supplement Survival Equipment Trip Expectations Marine Radio (Yes/No) Type Frequencies Departing From Number of PFDs Flares (Yes/No) Mirror (yes or no) Departure Date Departure Time Smoke Signals (Yes/No) Flashlight (Yes/No) Food (Yes/No)
- Page 51 Owner’s Notes...
- Page 52 Owner’s Notes...
- Page 53 Owner’s Notes...
- Page 54 Owner’s Notes...
- Page 56 Part Number 1700666 Bayliner • P.O. Box 9029 • Everett, WA98206 • 360-435-5571...
