- Page 1 ALL-PURPOSE INFLATOR CORDLESS AND RECHARGEABLE FOR RAFTS AND TIRES RECHARGEABLE RECHARGEABLE RECHARGEABLE ATTENTION! READ ALL INSTRUCTIONS CAREFULLY FAILURE TO FOLLOW WARNING INSTRUCTIONS CAN RESULT IN FIRE, PERSONAL INJURY OR PROPERTY DAMAGE. PART #40028...
- Page 2 CAUTION: HOT • DO NOT HOLD IN HAND WHILE OPERATING. PLACE INFLATOR ON A HARD, CLEAN SURFACE 1. DO NOT use inflator continuously for more than 10 minutes. Allow unit to cool approximately 25 minutes between uses. Do not leave inflator unattended. 2. DO NOT run vehicle while inflator is operating. Engine must be turned OFF. 3. DO NOT operate the inflator with a beverage in the cup holder. 4. ALWAYS use a pressure gauge to check actual tire pressure. DO NOT OVERINFLATE! 5. Keep inflator out of reach of children. 6. For use with 12-volt DC power outlets rated 15 amps or higher. Do not use with older 8 amp cigarette lighter receptacles.
- Page 3 Ball Raft Raft Raft & Raft & Raft & Mattress Mattress Mattress Two built-in cup holders Rubber bumpers Carrying handle Protective brushed Bright LED aluminum faceplate light High durability Battery level motor indicator Built-In Rechargeable battery Digital gauge with Inflate-Right™ On/Off buttons • Choose & set Light • pressure High pressure motor • • Inflator stops High volume motor • when set pressure is reached Inflate/deflate portals • For rafts and mattresses Rubberized feet • For added stability 120 volt High pressure air hose wall adapter • For tires 12 volt accessory High volume air hose...
- Page 4 HOW TO INFLATE TIRES: 1. Attach air hose to tire by fully screwing the connector onto the tire valve. 2. Plug power cord into power accessory outlet or leave unplugged to run from battery. NOTE: The unit will not run unless the gauge is turned on by pressing the “set” button. 3. To set the Inflate-Right™ system, press either arrow button under the display for 3 seconds until the target pressure blinks. HOLD FOR 3 SECONDS 4. Use the up and down arrow buttons to reach your target pressure. The inflator will store this pressure automatically after a few seconds. 5. To inflate, press the button with the tire symbol. TARGET PRESSURE Once your target pressure is reached, the inflator will shut off. The inflator can be manually shut off by pressing the tire symbol button again. 6. Unplug power cord (if necessary) and disconnect the air hose. NOTE: Correct tire pressure can be found in vehicle’s owner manual or driver’s side door jamb. TO TOGGLE PRESSURE UNITS (PSI/kPa/BAR): Press the “Set” button at the base of the gauge.
- Page 5 HOW TO USE RAFT PUMP: The raft air pump is used for inflatables only (more specifically, high volume/low pressure applications) and cannot be used for tires and balls which require higher pressure. 1. Attach raft hose to desired inflation adapter, and make sure connection is tight. 2. Connect hose to the inlet or outlet on the front of the inflator. The “+” side is used for inflation and “–“ for deflation. 3. Press button with the raft symbol to activate the raft pump. Once desired pressure is reached, turn power off and remove all connections. CAUTION: 1. While operating, never block the inflator input or output. 2. Soft inflatables (i.e. rafts, balls, etc.) may not have recommended pressure markings. Be careful not to inflate items beyond their capacity. 3. Never operate the inflator with a beverage in the cup holder. BATTERY: · Your unit has been initially charged. However, it is always good to top it off prior to use for full performance. · Note: It takes 16 hours to fully charge your battery from the wall (AC outlet). BATTERY LEVEL INDICATOR · Note: It takes 6 hours to fully charge from your car power outlet (DC outlet).
- Page 6 TROUBLESHOOTING: Inflator fails to operate when plugged in: 1. The fuse, located in the plug adapter, may have blown. 2. Unscrew the tip of the plug adapter, remove fuse and inspect. If necessary, replace fuse with one of the same amperage. Inflator does not start or blows fuses: 1. Push the power plug firmly into the receptacle and twist it back and forth (if using DC adapter plug). 2. Check receptacle and plug terminals for dirt and debris. (Use a non-conductive probe, not fingers or metal.) 3. Check vehicle’s power outlet fuse. It should be 15 amps minimum. 4. The Inflate-Right™ pressure may be set below the desired pressure. Reset. Inflator runs but does not inflate: 1. Be sure the connector is fully threaded on the tire valve. 2. Check tire for leaks, and check hose for breaks and leaks at fittings. Inflator runs slowly: 1. Possibly overheated from excessive use. Shut it off and allow to cool for 25 minutes. 2. Voltage may be too low. Check condition of vehicle battery. NOTE: If tire is totally deflated, it is possible that the tire could separate from the rim allowing air to leak out when trying to inflate. In the event this situation occurs, you will have to jack up the tire prior to inflation. BATTERY DISPOSAL: This product contains a rechargeable sealed lead-acid battery. The environmental laws in some counties require retailers to accept returns of rechargeable batteries for proper disposal. Check the county laws before disposing this...
