  • Page 1 INSTRUCTION MANUAL Combination Tool RESCUE TOOLS...

  • Page 2: Hydraulic Fluid

    PRODUCT SAFETY POLICY Hale Products, Inc. urges all users of Jaws of Life Jaws of Life products are designed and © products to read the Instruction Manual and to seek manufactured to provide excellent service when operating instructions from qualified instructors used for their intended purpose.

  • Page 3: Assembly / Storage

    Assembly / Storage Combi-Tool Remove rescue tool from carton; inspect unit and confirm that all bolts and screws are securely fastened, and the unit has not been damaged in shipment. Before starting the hydraulic power unit, connect the hoses from the power unit to the tool as shown.
  • Page 4 To operate the quick disconnect cou- plings, align the slot in the sleeve with the pin. Slide the sleeve back to con- nect or disconnect the coupling. After connecting coupling, rotate the sleeve one-quarter to one-half of a turn to lock the coupling.
  • Page 5 To attach optional chain and shackle accessories for pulling operation, slip tips over the ends of the blades until they are secure. Make sure both hooks are facing the same direction, up or down, to prevent the arms from twisting. Proper assembly shown.
  • Page 6 Spreading / Pulling MOC Combi-Tool To lift a steering column: Open blades to maximum spread. Place shackles over the blade tips, see page 4, step 6. Wrap chain around the steering column and slip hook over the chain. Using the above method, attach the other chain to the body frame under the bumper.
  • Page 7 Lift steering column by closing the tool. If the steering column has not been pulled far enough away from the victim when the tool jaws are fully closed, open jaws and shorten chain length by adjusting chains at the shackle until all the slack has been removed.
  • Page 8 Cutting MOC Combi-Tool CAUTION: HOLD BLADES PERPENDICULAR TO THE MATERIAL BEING CUT. MATERIAL TO BE CUT MUST BE SECURE SO THAT IT CAN NOT TWIST. WARNING: IF TOOL IS NOT HELD FIRMLY OR IF THE MATERIAL IS FORCED BETWEEN THE BLADE FLATS, BLADE DAMAGE MAY RESULT.
  • Page 9 To cut, open tool. Place blades around object. Close tool to cut object. Maximum cutting forces are obtained at the portion of the blade nearest the blade pin or center pivot pin. When possible, start your cut at this point. After making cut, open blades to remove tool.

  • Page 10: Troubleshooting Guide

    Clean unit with soap and water Clean unit with soap and water. TRAINED PERSONNEL. Check hydraulic fluid level in reservoir and fill if necessary. Use only HURST Disassemble and inspect all parts and PHOSPHATE ESTER hydraulic fluid. seals for wear or damage. Replace as Use of any other fluid will damage seals necessary.
  • Page 11 NOTES:...
  • Page 12 PRINTED IN USA 0407 PART NO. 159R173 REV. 01 ©2007 Hale Products, Inc. A Hale Products, Inc. reserves the right to make changes at any time, without notice or obligation, in prices, materials, equipment or specifications and to change or discontinue models. Check with distributor for current information.
