Carrier WeatherMaker 48FC04-07 Installation Instructions Manual

Single package rooftop gas heating/electric cooling unit with puron r-410a refrigerant
Hide thumbs
Table of Contents

Advertisement

Quick Links

CONTENTS
SAFETY CONSIDERATIONS . . . . . . . . . . . . . . . . . . . . . .1
DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Rated Indoor Airflow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Jobsite Survey. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Step 1 - Plan for Unit Location. . . . . . . . . . . . . . . . . . .7
Step 3 - Inspect Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Step 4 - Provide Unit Support . . . . . . . . . . . . . . . . . . .7
Step 5 - Field Fabricate Ductwork . . . . . . . . . . . . . . .9
Step 6 - Rig and Place Unit . . . . . . . . . . . . . . . . . . . . . .9
Ductwork . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Step 8 - Install Outside Air Hood . . . . . . . . . . . . . . .11
HOOD PACKAGE REMOVAL AND SETUP
(FACTORY OPTION)
Step 10 - Install Flue Hood . . . . . . . . . . . . . . . . . . . . .12
Step 11 - Install Gas Piping. . . . . . . . . . . . . . . . . . . . .13
and Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
®
Integrated Gas Controller . . . . . . . . . . . . . . . . . . . . . . .25
X (Factory Option) . . . . . . . . . . . . . . . . .27
®
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Catalog No. 04-53480209-01
Installation Instructions
Page
Printed in U.S.A.
Form 48FC-4-7-01SI
48FC04-07 Single Package Rooftop
Gas Heating/Electric Cooling Unit
®
with Puron
RTU Open Controller (Factory Option). . . . . . . . . . . 41
Controller Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Smoke Detectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Step 15 - Install Accessories . . . . . . . . . . . . . . . . . . . 42
Step 16 - Fan Speed Set Up . . . . . . . . . . . . . . . . . . . . 43
START-UP CHECKLIST. . . . . . . . . . . . . . . . . . . . . . . .CL-1

SAFETY CONSIDERATIONS

Improper installation, adjustment, alteration, service,
maintenance, or use can cause explosion, fire, electrical
shock or other conditions which may cause personal injury or
property damage. Consult a qualified installer, service agen-
cy, or your distributor or branch for information or assistance.
The qualified installer or agency must use factory-authorized
kits or accessories when modifying this product. Refer to the
individual instructions packaged with the kits or accessories
when installing.
Follow all safety codes. Wear safety glasses and work
gloves. Use quenching cloths for brazing operations and have
a fire extinguisher available. Read these instructions thor-
oughly and follow all warnings or cautions attached to the
unit. Consult local building codes and appropriate national
electrical codes (in USA, ANSI/NFPA70, National Electrical
Code (NEC); in Canada, CSA C22.1) for special require-
ments.
It is important to recognize safety information. This is the
safety-alert symbol
unit and in instructions or manuals, be alert to the potential
for personal injury.
Understand the signal words DANGER, WARNING,
CAUTION, and NOTE. These words are used with the safety-
alert symbol. DANGER identifies the most serious hazards
which will result in severe personal injury or death. WARNING
signifies hazards which could result in personal injury or death.
CAUTION is used to identify unsafe practices, which may result
in minor personal injury or product and property damage. NOTE
is used to highlight suggestions which will result in enhanced in-
stallation, reliability, or operation.
Electrical shock can cause personal injury and death. Shut
off all power to this equipment during installation and ser-
vice. There may be more than one disconnect switch. Tag
all disconnect locations to alert others not to restore power
until work is completed.
Pg 1
1018
WeatherMaker
(R-410A) Refrigerant
. When you see this symbol on the
WARNING
8-18
Replaces: NEW
®
Page
