- Page 1 USER, INSTALLATION AND SERVICING INSTRUCTIONS Please read these instructions before installation and use Keep this booklet handy for future reference N E W DAW N...
-
Page 2: Table Of Contents
CONTENTS USER’S INSTRUCTIONS INSTALLER’S INSTRUCTIONS INSTALLATION - SLIM AND DEEP MODELS INSTALLATION - POWERFLUE MODEL FIT THE BURNER FIT THE SURROUND PLACEMENT OF CERAMICS PEBBLE AND COAL - DEEP MODEL DRIFTWOOD AND CHARCOAL - DEEP MODEL PEBBLE AND COAL - SLIM AND POWERFLUE FAULT FINDING - POWER FLUE VERSION COMMISIONING AND SERVICING... -
Page 3: User's Instructions
USER’S INSTRUCTIONS - ALL VERSIONS TO ACCESS THE CONTROLS To access the controls simply pull the bottom of the Corian surround forward as shown here. The surround is hinged at the top to allow it to open. The controls can be seen through the fire opening and are accessed from below the Corian surround. - Page 4 MANUAL CONTROL VERSION REMOTE CONTROL VERSION The gas control is situated centrally behind the TO LIGHT THE FIRE front surround. Piezo ignition is used to light the Point the handset at the sensor on the fire, pilot, which can also be lit with a match. The situated centrally underneath the surround.
- Page 5 TO INCREASE THE HEAT SETTING AUTO HANDSET STORAGE Point the handset at the sensor on the fire. When the handset is not in use it can be stored Press and hold the plus button (marked with a out of view inside the appliance body at the right large flame).
- Page 6 Lift the battery holder out (Figure 7B). The CLEANING THE CORIAN SURROUND batteries can now be removed. It is easiest to For every day cleaning use a damp cloth and remove the middle battery first on each side of detergent, wipe clean with a clean damp cloth the holder.
- Page 7 combustion are entering the flue and that there SPARES & SERVICE is no excessive build up of soot or debris, excessive quantities of soot or debris on the fire Replacement parts are available from your will require removal, refer to “CLEANING“. If a supplier or through our mail order service.
- Page 8 INSTALLATION INSTRUCTIONS - ALL VERSIONS INTRODUCTION TECHNICAL INFORMATION This fire is CE approved to the European NATURAL GAS (G20) DEEP Standard EN 509 and is intended for decorative Heat Input Max (gross): 7.0 kW purposes. Heat Input Min (gross): 4.1 kW Inlet Pressure: 20 mbar The fire must be installed and serviced by a...
- Page 9 To comply with European Regulations the FLUE fireplace must have a non-combustible hearth The chimney/flue may be class 1 or 2 and must not less than 12mm thick. The edge of the have a height of at least 3m with an internal hearth which may be in the form of a raised lip, diameter of not less than 125mm.
- Page 10 when positioned in the cavity box must be packed INSTALLATION IN TIMBER FRAME BUILDINGS with 50mm of Rockwool or equivalent material PF MODELS and the top must be packed with 100mm of These instructions are to serve as guidance only, Rockwool .
- Page 11 with 50mm of Rockwool , and the top must be packed with 100mm of Rockwool . NOTE: The Rockwool must not overhang the wall cavity. The fan unit must not be installed into any combustible materials. If the outer layer of the wall is combustible then the fan unit must be surface mounted using the spacer (optional ®...
-
Page 12: Installation - Slim And Deep Models
INSTALLATION - SLIM AND DEEP MODELS C.1 REMOVE THE BURNER MANUAL CONTROL MODELS 3 Screws Wing Nuts Fire Trim 1. Remove the 4 wing nuts that secure the 2. Remove the 3 screw that secure the burner fire trim to the wall plate. Place the fire to the firebox. - Page 13 C.2 PREPARE THE FIREPLACE OPENING ALL MODELS WIDTH 5. Prepare the opening in the wall referring to the dimensions given in the table on page 9. Ensure that the bottom of the opening is flat and level and that all gaps at the base of the opening are properly sealed.
- Page 14 C.4 SLIM VERSION - FIT SPACER FRAME SLIM MODEL WITH SPACER ONLY Drill, Plug, and Screw Spacer Frame Screws x 15 8. Remove the spacer from the rear of the 9. Position the spacer frame on the wall firebox by removing the 15 self tapping ensuring that the base of it is level with the screws around the edge of the Wall Plate.
- Page 15 C.5 FIT THE FIREBOX SLIM MODEL WITH SPACER ONLY Screw in Place (15 Screws) Rear Inspection Plate Gas Supply Entry 10. Remove the Rear Inspection Panel from 11. Prepare the gas supply noting the entry the firebox by removing the 4 screws. The point in the rear of the firebox.
-
Page 16: Installation - Powerflue Model
INSTALLATION - POWERFLUE MODEL when installed the flue terminal position conforms to the requirements in diagram D.10. Please bear this in mind when choosing a location to install the fire. 3 Screws Measure the required height to the bottom of the fireplace opening from the floor and draw a horizontal line on the wall at the same height. - Page 17 Rear Inspection Panel Fan Box Opening Gas Entry Point Outer Inner Wall Wall Gas Supply Pipe Fire Isolating Tap Opening Plaster Wall Plate Painted Cover Fixing Screws (4) Screws Rope Seal Flue Fan Unit Duct Fan Unit Screws (4) Painted Cover Mark Flue Cable Duct Here...
- Page 18 flanges of the wall plate are all touching the INSTALLING THE FAN BOX wall and the flue duct is central in the wall plate Take the wall plate and insert it into the spigot. Ensure that the cable entry hole is at the opening in the outer wall ensuring that the flue top right.
- Page 19 POWERFLUE TERMINAL LOCATIONS † The minimum acceptable distances from the edge of the flue terminal to obstructions and openings are as stated in the table below:- MINIMUM DIMENSIONS † 300mm below, above or next to an opening 75mm below gutters, drain or soil pipes 150mm from a vertical drain or soil pipe 300mm horizontally from an existing terminal 1500mm vertically from an existing terminal...
-
Page 20: Fit The Burner
FIT THE BURNER MANUAL MODELS Gas Supply Pipe 1. Cut a 70mm length of copper pipe and attach it to the isolating tap supplied. 70mm Copper Pipe Shape and cut the gas supply pipe and ensuring the gas supply pipe is clean internally connect to the isolating tap. -
Page 21: Fit The Surround
FIT THE SURROUND ALL MODELS Hinge Slot Insert Tabs into Slots Hinge Tab Damper Remove all the packaging from the With the Surround tilted at an angle, align Surround. Note the positions of the slots in the Surround centrally with the Firebox the top of the Firebox Frame. -
Page 22: Placement Of Ceramics
DEEP MODEL ONLY PLACEMENT OF CERAMICS - PEBBLE AND COAL Underbed MUST SIT BEHIND THESE TABS ON THE BURNER Front Piece 1. Locate the base of the front ceramic piece 2. Holding the underbed by the top rear, up against the brackets at the front edge, position it against the front ceramic piece. - Page 23 DEEP MODEL ONLY PLACEMENT OF CERAMICS - DRIFTWOOD AND CHARCOAL Underbed MUST SIT BEHIND THESE TABS ON THE BURNER Front Piece 1. Locate the base of the front ceramic piece 2. Holding the underbed by the top rear, up against the brackets at the front edge, position it against the front ceramic piece.
- Page 24 SLIM AND POWERFLUE MODELS ONLY PLACEMENT OF CERAMICS - PEBBLE AND COAL Underbed MUST SIT BEHIND THESE TABS ON THE BURNER Front Piece 1. Locate the base of the front ceramic piece 2. Holding the underbed by the top rear, up against the brackets at the front edge, position it against the front ceramic piece.
-
Page 25: Fault Finding - Power Flue Version
FAULT FINDING - POWER FLUE VERSION If at any point the flue flow falls below a pre set GENERAL OPERATION value the fan will revert to full speed for 8 Refer to wiring diagrams on the next page. seconds. If this does not restore sufficient flue With the ON/OFF switch set to position 1 flow then the gas supply to the fire will be shut (ON) the PCB checks that the air pressure... - Page 26 FAN SWITCH WIRING DIAGRAM White Orange Blue Brown Grey Brown Blue Green / Yellow Earth Post Black Brown Blue FAN BOX WIRING DIAGRAM Blue Green/Yellow Purple Molex 6 Way Molex 4 Way Orange Socket Green/ Warm Up Overheat Yellow T/Stat T/Stat Molex 4 Way Pressure...
-
Page 27: Commisioning And Servicing
COMISSIONING AND SERVICING COMISSIONING SERVICING Ensure the Isolating tap is fully open and check Pull the bottom of the Corian surround forward. for gas leaks. Then lift the whole surround upwards to clear the hinge tabs. Place the surround to one side taking Connect a pressure gauge to the inlet pressure care not to damage it. - Page 28 Brilliant Fires Limited Thwaites Close Blackburn BB1 2QQ England tel +44 (0)1254 682384 fax +44 (0)1254 672647 www.brilliantfires.co.uk info@brilliantfires.co.uk 04 11 2010...
