The AI1422E Reader User Guide provides information necessary for
interfacing the AI1422E Reader System to a host computer system.
Purpose of This Guide
This user guide provides information for interfacing the AI1422E Reader System
with a host computer system. This guide provides on-site test procedures useful in
troubleshooting any problems encountered after installation. Command codes, which
allow the user to configure the reader system for communicating with the host computer,
are discussed as is ASCII character conversion to TransCore 6-bit character codes.
Intended Audience
The intended audience for the AI1422E Reader User Guide are skilled personnel
(including trained engineers and technicians). These people are involved in the design,
specification, and installation of AI1422E Reader Systems.
1422E Reader
User Guide
16-0058-001 Rev A5 9/16
Trusted Transportation Solutions
