Motorola Moto Surround S505 Quick Start Manual

Moto Surround
Quick Start Guide
Product Overview
1
2
3
1 Headband
Adjustable slider
2
Adjust the headband to fit your head size.
Left earpiece
3
Built-in rechargeable battery.
4 Right earpiece
Micro USB power port
5
Connect an USB cable for charging.
6
Microphone
Use to speak for a call or voice recognition.
LED indicator
7
Adjustable slider
8
Adjust the headband to fit your head size.
Charging the Built-in Battery
To compute USB port,
or USB power adapter
4 5 6
The unit has been equipped a built-in rechargeable battery. To charge it, connect one end of the
USB cable to the Micro USB power port of this unit, the other end to computer USB port or
USB power adapter. The LED indicator will display the charging status:
Lights in red
Lights in green
You can also check the built-in battery power by pressing + and – button simultaneously when
this unit is not in a call. The LED indicator will display the battery power level as follows:
Lights in red
Lights in yellow
Lights in green
Note:
• When this unit is connected to an iOS device, a battery icon will appear on the screen
next to the Bluetooth icon to indicate the built-in battery power of this unit.
7 8 9
9 MFB button
- Press to start/pause music playback.
- Press to answer/end a call.
Volume +/– button
10
- Press to adjust the volume levels.
- During music playback, press and hold + button to skip to
the next track; press and hold – button to skip to the
previous track.
- When a call is coming, press and hold + or – button to
dismiss it; during a call, press + and – button simultane-
ously to mute the microphone.
Power button
11
Press to turn on/off this unit.
Power is less than 90%
Power is more than 90%, or full charged
0~19%
20%~70%
71%~100%
10 11
S505
