PART NAMES

FRONT
BACK
11
12
1
Main Unit
2
Air Outlet
3
Fan Speed Indicator Lights(green)
MODE Button / LIGHT ON/OFF Button
4
(Press 3 sec.)
5
Plasmacluster Ion Indicator Light(blue)
6
Plasmacluster Ion ON/OFF Button
7
POWER ON/OFF Button
ANTI DUST Button / ANTI DUST indicator
8
Light(green)
OM_FP-F30Y_EN-ID.indd 4
2
1
9
10
16
E-4
3
4
13
14
15
9
HEPA Filter
10
Upper Tabs
11
Back Panel (Pre-Filter)
12
Bottom Tabs
13
Handle
14
Date Label
15
Power Cord
16
Plug (Shape of plug depends on country.)
