The Back Panel - TP-Link Archer C3150 User Manual

Chapter 1
Name
(WPS)
(USB1)
(USB2)
Note:
After a device is successfully added to the network by WPS function, the WPS LED will keep on for about 5 minutes
and then turn off.
1. 3. 2.

The Back Panel

The router's back panel shows the connection ports, buttons and antennas (view from
left to right). Refer to the following for detailed instructions.
Item
Internet
LAN1, LAN2, LAN3,
LAN4
Power
LED Explanation
Status
A wireless device has been successfully added to the network by
On
WPS function.
WPS handshaking is in process and will continue for about 2 minutes.
Flashing Please press the WPS button on other wireless devices that you want
to add to the network while the LED is flashing.
Off
The router is not in the WPS process.
On The USB 3.0 device is identified and ready to use.
Flashing The USB 3.0 device is being identified.
No USB 3.0 device is plugged into the USB port or the USB device is
Off
not identified or USB device has been safely ejected.
On The USB 2.0 device is identified and ready to use.
Flashing The USB 2.0 device is being identified.
No USB 2.0 device is plugged into the USB port or the USB device is
Off
not identified or USB device has been safely ejected.
This port is where you will connect the DSL/cable Modem, or Ethernet.
These ports (1, 2, 3, 4) connect the router to the local PC(s).
For connecting the router to power socket via the provided power adapter.
Get to Know About Your Router
Indication
Description
6
