For 1500 VA, 2200 VA, and 3000 VA uninterruptible power
supplies and 2200 VA and 3000 VA extended battery modules
Use the instructions in this document to install the 1500 VA, 2200 VA, and 3000 VA uninterruptible power
supplies and 2200 VA and 3000 VA extended battery modules in a rack cabinet.
Review the documentation that comes with your rack cabinet for safety and cabling information.
When you install the uninterruptible power supply or extended battery module in a rack cabinet, observe
the following precautions:
v The extended battery module and uninterruptible power supply internal battery and chassis are heavy.
Make sure that you have the minimum number of persons required to lift the components. See Table 1
on page 6 and Table 2 on page 7.
v Make sure that the room air temperature is below 35°C (95°F).
v Do not block any air vents; usually 15 cm (6 in.) of air space provides proper airflow.
v Plan the device installation starting from the bottom of the rack cabinet.
v Install the heaviest device in the bottom of the rack cabinet.
v Do not extend more than one device out of the rack cabinet at the same time.
v Connect all power cords to properly wired and grounded electrical outlets.
v Do not overload the power outlet when you install multiple devices in the rack cabinet.
You will need a Phillips screwdriver to install the uninterruptible power supply or extended battery
module in a rack cabinet.
Note: The illustrations in this document might differ slightly from your hardware.
The following parts come with the rack mounting kit:
v One right adjustable rail
v One left adjustable rail
v Four adapter plates with adhesive (for round hole racks)
v Sixteen M5 x 16 mm Phillips screws
Note: Removing the rack doors and side panels might make installation easier. See the rack cabinet
documentation for more information.
Rack Installation Instructions

Advertisement

loading
Need help?

Need help?

Do you have a question about the 1500 VA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for IBM 1500 VA

  • Page 1 2200 VA and 3000 VA extended battery modules Use the instructions in this document to install the 1500 VA, 2200 VA, and 3000 VA uninterruptible power supplies and 2200 VA and 3000 VA extended battery modules in a rack cabinet.
  • Page 2 DANGER Electrical voltage and current from power, telephone, and communication cables are hazardous. To avoid a shock hazard: v Do not connect or disconnect any cables or perform installation, maintenance, or reconfiguration of this product during an electrical storm. v Connect all power cords to a properly wired and grounded electrical outlet. Ensure outlet supplies proper voltage and phase rotation according to the system rating plate.
  • Page 3 CAUTION: >32 kg (70.5 lb) 32-55 kg (70.5-121.2 lb) The weight of this part or unit is between 32 and 55 kg (70.5 and 121.2 lb). It takes three persons to safely lift this part or unit. (C010) Installing an uninterruptible power supply or extended battery module in the rack cabinet To install an uninterruptible power supply or extended battery module in the rack cabinet, complete the following steps:...
  • Page 4 2. Loosen the rail adjustment screw and adjust the left and right rail length to the depth of the rack cabinet. 3. Select a location in the bottom of the rack cabinet for the uninterruptible power supply or extended battery module. 4.
  • Page 5 7. For uninterruptible power supply installation only: To reduce the weight of the uninterruptible power supply, remove the internal battery module: a. Loosen the thumbscrew on the metal battery cover 1 , slide the cover to the right 2 , and open the cover 3 .
  • Page 6 Some battery modules might require two people to lift it. Table 1. Internal battery module handling requirements Battery description Weight Handling requirement 1500 VA internal battery module 8 kg (18 lb) One person 2200 VA internal battery module 16.3 kg (36 lb)
  • Page 7 Table 2. Uninterruptible power supply and extended battery module handling requirements Machine type-model or part number Product description Weight Handling requirement 5395-1AX 1500 VA 2U rack 10.2 kg (22.6 lb) (chassis only) One person uninterruptible power supply 5395-1KX 1500 VA 2U rack 11.3 kg (25 lb) (chassis only) One person...
  • Page 8 11. For uninterruptible power supply installation only: To reinstall the battery module, complete the following steps: a. Loosen the thumbscrew on the metal battery cover 1 , slide the cover to the right 2 , and open the cover 3 .
  • Page 9 Table 3. Internal battery module handling requirements Battery description Weight Handling requirement 1500 VA internal battery module 8 kg (18 lb) One person 2200 VA internal battery module 16.3 kg (36 lb) One person 3000 VA internal battery module 21.3 kg (47 lb)
  • Page 10 d. Close the metal battery cover 1 , then slide the cover slightly to the right and then to the left 2 . Tighten the thumbscrew 3 . 12. Locate the bezel that comes with the uninterruptible power supply or extended battery module. Press the two side latches toward each other, align the bezel with the uninterruptible power supply or extended battery module, and snap it into place.
  • Page 11 13. Remove the clear protective film that covers the liquid crystal display (LCD) on the front of the uninterruptible power supply. For more information about installing and operating the uninterruptible power supply and extended battery module, see the Installation and Maintenance Guide that comes with the uninterruptible power supply.
  • Page 12 Second Edition (May 2011) IBM is a trademark of International Business Machines Corporation in the United States, other countries, or both. Printed in USA © Copyright IBM Corporation 2010, 2011. US Government Users Restricted Rights – Use, duplication or disclosure restricted by GSA ADP Schedule Contract with IBM Corp.
