GridScan/Mini-SB2/-ST2

18.2 FSS Control Unit

Synchronization
cable
Tx Rx
Supply voltage
Dimensions
Enclosure rating
Certificates
Safety category
Ordering information

18.3 FSS Control Unit (for DIN-rail)

Synchronization
cable
Tx Rx
Supply voltage
Dimensions
Enclosure rating
- Housing
- Terminal
Certificates
Safety category
Ordering information
14
U edges
SP
Not used
Test input
Output (FSS)
GND (0 V)
Not used
U edges
SP
Not used
Test input
Output (FSS)
GND (0 V)
Not used
M8, 6-pin
1
brown
2
gray
3
white
4
black
5
blue
6
green
24 VDC or 230 VAC
130 × 94 × 57 mm
IP56
CE, TÜV
EN ISO 13849-1 2008 Cat.3 PL C
Part No. 112 183 (24 VDC)
Part No. 113 119 (230 VAC)
M8, 6-pin
1
brown
gray 2
3
white
4
black
5
blue
green 6
24 VAC/DC
22.5 × 100 × 120 mm
IP40
IP20
CE, TÜV
EN ISO 13849-1:2008 Cat.3 PL D
Part No. 112 184
English
FSS Control Unit
1 BN A1
U
SP
WE A2
2
4 GN1
33
5
6
34
FSS Control Unit
bn
A1
U
SP
A2
X2
Reset
gn1
X3
gn2
13
gn3
gn4
we
14
