Summary of Contents for Cedes TOF/Start
- Page 1 TOF/Start Installation and Operation Manual RoHS CEDES AG is certified according to ISO 9001: 2015 English Pages 2 – 11 114 474 | 180219 | V 1.1...
-
Page 2: Table Of Contents
CH-7302 Landquart Timing diagram Switzerland LED signals Cross-traffic Blanking Trouble shooting Maintenance Disposal Technical data Dimensions 17.1 Sensor 17.2 Mounting bracket CEDES AG reserves the right to modify or change technical data without prior notice. © CEDES | V 1.1... -
Page 3: Safety Information
Safety messages categories Keep the instruction manual on site. Warning of serious health risks The TOF/Start should only be installed by authorized and WARNING fully trained personnel! The installer or system integrator is fully responsible for the safe integration of the sensor. It is... -
Page 4: Introduction
Type description The TOF/Start is a compact yet powerful sensor which detects TOF/Start – a – bb – c – d – e – fff; g; h,h*i,i people and objects approaching an escalator and speeds it up in time for them to step comfortably and safely aboard. -
Page 5: Installation
3. Check the distance setting and the reaction of the Important: sensor, including the status LED, by placing an object The TOF/Start must be mounted under the handrail at a into the detection area at different heights and widths. minimum 10° mounting angle to the ground facing upwards. -
Page 6: Timing Diagram
Power-on time 1,000 Max. response time - TOF/Start Basic - TOF/Start Advanced • Area without cross-traffic < 1 m • Area with cross-traffic > 1 m Release time Min. switching time Figure 8: General timing table © CEDES | V 1.1... -
Page 7: Led Signals
The TOF/Start Advanced features a cross traffic detection function. If a person moves towards the escalator entrance area, the TOF/Start Advanced triggers the output. If the person only moves across the escalator entrance area, the TOF/Start Advanced recognizes that the person does not Figure 12: Detection field free;... -
Page 8: Blanking
TOF/Start English 12. Blanking Both TOF/Start versions feature a blanking function. The TOF/Start triggers the output when objects are dynamic (moving) within the detection field. Static objects within the LED bright detection field will be ignored and blanked out (after 30 seconds). -
Page 9: Maintenance
Material PVC, black 15. Disposal Plug color Blue Wires AWG26 The TOF/Start should only be replaced if a similar brown • protection device is installed. Disposal should be done blue GND (0 V) using the most up-to-date recycling technology according •... -
Page 10: Dimensions
TOF/Start English 17. Dimensions 17.1 Sensor Measurements (all dimensions in mm and inches) 52 (2.05) 29 (1.14) 57 (2.24) 17.2 Mounting bracket Measurements (all dimensions in mm and inches) 68.35 (2.69) 33.35 (1.31) © CEDES | V 1.1... - Page 11 TOF/Start English © CEDES | V 1.1...
- Page 12 TOF/Start CEDES AG, Science Park | CH-7302 Landquart Phone: +41 81 307 2323 | Fax: +41 81 307 2325 | info.eu@cedes.com | www.cedes.com...
