GridScan/Mini
Installation and Operation Manual
Montage- und Betriebsanleitung
RoHS
EN 13849-1
C
US
CEDES AG is certifi ed according to ISO 9001: 2008
CEDES AG ist zertifi ziert nach ISO 9001: 2008
English
Deutsch
111 726 | 130306 | V 2.1
Pages 2 – 16
Seiten 17 – 30

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GridScan/Mini and is the answer not in the manual?

Questions and answers

Summary of Contents for Cedes GridScan/Mini

  • Page 1 GridScan/Mini Installation and Operation Manual Montage- und Betriebsanleitung RoHS EN 13849-1 CEDES AG is certifi ed according to ISO 9001: 2008 CEDES AG ist zertifi ziert nach ISO 9001: 2008 English Pages 2 – 16 Deutsch Seiten 17 – 30...
  • Page 2: Table Of Contents

    8.5 Output 2 9. Timing diagram 10. Start-up 11. LED status description 12. Troubleshooting 13. Maintenance 14. Disposal 15. Technical data 16. Dimensions © CEDES | V 2.1 CEDES AG reserves the right to modify or change technical data without prior notice.
  • Page 3: Safety Information

    Any alterations to the device by the buyer, installer 2 of this manual or user may result in unsafe operating conditions. CEDES is not responsible for any liability or warranty Caution of possible health risks claim that results from such manipulation.
  • Page 4: Introduction

    GridScan/Mini 4. Introduction 4.2 Type description The GridScan/Mini is a very compact, SIL 2-certified GRS/Mini – xx – xxxx – xx, xx, x, x, x safety light curtain, designed to safeguard any type Output 2 (Optional) of door and gate, with a maximum operating range of...
  • Page 5: Overview

    (SB and DB type  Chapter 4.2) is designed to mount directly into the guide rails. As the door closes, the GridScan/Mini recognizes the door as such and does not switch the output. Figure 3: Sectional doors with door blanking...
  • Page 6: General Instruction And Precaution

    Avoid interference from blinking lights or infrared light sources such as photo cells or other light curtains. Do not install the GridScan/Mini in places where the emitter and receiver edges are directly exposed to light sources such as FL tubes or energy saving lamps.
  • Page 7: Gridscan/Mini Product Overview

    Figure 7: GridScan/Mini product overview 6. Application overview Synchronization cable Door operator Connection cable Receiver edge Emitter edge Figure 8: GridScan/Mini with door blanking (SB and DB type) Door controller Figure 10: GridScan/Mini application overview Figure 9: GridScan/Mini static mounting (ST type)
  • Page 8: Door Blanking (Sb And Db Type)

    GridScan/Mini 6.1 Door blanking (SB and DB type) The GridScan/Mini can differentiate between a light beam interruption caused GridScan/Mini edge by an object and a light beam interruption caused by the closing door. Optical element The GridScan/Mini does this by analyzing the different interruption patterns.
  • Page 9: Electrical Connection

    Important: Any unconnected (not used) wire must be separated and isolated. 8.1 Output 1 When an object enters the surveillance area (OBJECT DETECTED) the GridScan/Mini output changes after response time t . When the object leaves the surveillance area (NO OBJECT) the GridScan/Mini output switches back after release time t ...
  • Page 10: Fss (Frequency Safety Signal)

    GridScan/Mini output switches after test response closing cycle. time t GridScan/Mini is available with test active LOW and When the test switches back to HIGH, the test active HIGH  Chapter 4.2. GridScan/Mini output also switches back within...
  • Page 11: Timing Diagram

    No Power or not within the limits   Internal Malfunction  Table 5: LED status description emitter edge Table 4: LED status description receier edge = LED on = LED off = LED blinking   © CEDES | V 2.1...
  • Page 12: Troubleshooting

    (e.g. that any interruption vibrations do not cause edges to become misaligned). If a problem persists, please contact your local CEDES representative. Visit www.cedes.com for contact data. 13. Maintenance 14. Disposal Although the GridScan/Mini does not need regular...
  • Page 13: Technical Data

    Blue Wires AWG26 • brown (10 ... 30 VDC) • blue GND (0 V) • black Output 1 • white Test input • gray LO/DO selector • green Output 2 (optional, SB and DB type) © CEDES | V 2.1...
  • Page 14 EN 60068-2-6:2008 Shock IEC 60068-2-27:2009 RoHS 2011/65/EU Certificates CE, CSA, TÜV Safety category EN ISO 13849-1:2008, Cat. 2, PL D (excl. IEC 61496-2:2006) EN 61508:2011, SIL 2 EN 12978:2009 (SB type) Applicable standards UL 325:2012 © CEDES | V 2.1...
  • Page 15: Dimensions

    Receiver edge Emitter edge up to 2730 up to 2500 Ø 4.6 Ø 5 uS measurements (all dimensions in inches) Receiver edge 0.28 Emitter edge 0.87 up to 107.5 up to 98.5 Ø 0.18 Ø 0.2 © CEDES | V 2.1...
  • Page 16 GridScan/Mini © CEDES | V 2.1...
