LEO/LEO2 Plasma Mount
Ceiling mount for flat displays and TV
LIST OF ITEMS::
Mount
Mounting set
Installation manual
1. Installation & Adjusment:
A.
Prepare an installation place on the ceiling. Element A
install on a ceiling. Then install element C. On expected height
install element D(according to picure below). Use mounting
screws from mounting set.
.
C.
mounting arms B attach do back side of display/TV, using
mounting screws from mounting set.
B.
Using screws E adjust proper height of the mount.
D.
On a element D hang Flat screen with already mounted
arms B. Tighten the locking screws until you feel resistance
WARNING! Correct mounting of elements is required for
safety usage (as on piture below)
1/2
