Blaupunkt LS 230e Quick Start Manual

LS 230e
Quick Start Guide to connect Blaupunkt LS 230e to TV set or to an audio source
LS 230e has following audio inputs:
• Analogue stereo input
• Digital coaxial input
• Digital optical input
It will depend on the signal source that you have (TV, audio system, etc.) which audio input you shall use. The
majority from modern TV sets have for example an analogue headphone jack and a digital audio output (coaxial
digital or optical digital depending on the model/brand). We suggest that you use the digital output. Please do not
forget that it shall be activated and connected in the menu from your audio source.
Problem Solution
No sound Please check the connections between LS 230e and your TV.
No sound If you are using a digital output from your TV please confirm if it is activated on the menu
from your TV.
No sound Please confirm that the correct audio source from LS 230e is correctly chosen. You can
chose it with the remote control. The selected audio source will be shown in the display
from LS 230e.
No sound If you are using the digital input please confirm that PCM (digital stereo signal) audio
source is selected in your TV.
Please check if MUTE function is activated in your TV. If yes, please deactivate it otherwise
No sound
there will be no audio transmission to LS 230e.
Low volume Please confirm which volume level you have selected in your TV. If you select a low volume
level it will not allow that LS 230e has a good sound performance. Volume level from TV
shall be above 2/3 from maximum volume. We suggest that you select TV volume level
at almost maximum level.
Bad sound If you are using digital inputs please confirm that you have selected PCM (digital stereo
signal) audio source in your TV.
Bad sound Please confirm if the LS 230e speakers are working simultaneously with TV speakers: this
can originate a poor sound performance. Please check the instruction manual from your
TV to change it.
Too much or Many TVs have their own equalizer. Some TVs allow to make individual sound adjustments
almost no bass
for each output signal. Please confirm if they are activated and please change them in the
menu from your TV.
Too much or Many TVs have their own equalizer. Some TVs allow to make individual sound
almost no treble
adjustments for each output signal. Please confirm if they are activated and please
change them in the menu from your TV.
The sound bar LS 230e complies with the latest EU energy efficiency directive: it will automatically
turns off by itself
switch into stand-by mode in case of low or no audio signal input. Please verify which
is the volume level from the audio source.
Your individual audio settings will be memorized if LS 230e is in stand-by mode (power

Audio settings

were not consumption <1 Watt). If you switch off LS 230e it may be necessary that you have to
memorized
adjust again the audio settings after you turn on the device.

The optical cable

Please click the optical cable and make pressure to avoid that it slips away.
slips from the
optical input
Blaupunkt Competence Center Audio
M3 Electronic GmbH
March 2014 (V2.2)
Technical changes and errors excepted
