- Page 1 AutroSense 75 Aspirating Detector Installation & Commissioning Handbook Protecting environment, life and property... P-ASENSE75/IE 980302...
- Page 2 COPYRIGHT This publication, or parts thereof, may not be reproduced in any form, by any method, for any purpose. Autronica AS and its subsidaries assume no reponsibility for any errors that may appear in the publication, or for damages arising from the information in it.
-
Page 3: Table Of Contents
3.4 Pipe joints ................... 13 3.5 Cleaning out the pipe system following installation ......13 3.6 Concealed pipes.................. 14 3.7 Connecting to the AutroSense 75 detector unit ........14 3.8 Installing a “moisture trap”..............14 Installation & Commissioning Handbook, ,... - Page 4 4. Commissioning the system ..........15 4.1 Responsibility for commissioning the system ........15 4.2 Pre-commissioning check-list............. 15 4.3 Setting addresses - analogue addressable system ....... 16 4.4 Setting switches for monitoring the air flow ........16 4.5 Power supply ..................17 4.6 Configuration of air-flow monitoring..........
-
Page 5: Introduction
• BW-75/KON for a conventional system 1.3 Application AutroSense 75 is designed for use in all situations, including corrosive and dusty environments. The detector can be adapted to suit the prevailing conditions and provide the required detection level by using detector chambers with different levels of sensitivity. -
Page 6: Other Reference Documents
Introduction 1.5 Other reference documents Further information concerning the AutroSense 75 aspirating detector is found in the following: Manual Article no. Operating Manual P-ASENSE75/FE Data Sheet for the AutroSense 75 aspirating detector P-AS75/CE Installation & Commissioning Handbook, , P-ASENSE75/IE 980302, 7483 Trondheim... -
Page 7: Installation
Installation 2. Installation 2.1 Recommended height for mounting 175 cm 2.2 Dimensions Installation & Commissioning Handbook, , P-ASENSE75/IE 980302, 7483 Trondheim Page 5... -
Page 8: Positioning Of The Detector
Installation 2.3 Positioning of the detector If the pipes are to be installed in rooms with different pressures, the detector should be located in the room with the lowest pressure. In a building where the ventilation system causes a substantial negative pressure, the detector should be located in the room in which the pipe system is installed. -
Page 9: Cable Entry
Installation 2.5 Cable entry The power supply and loop cables are fed in through the underside of the unit via threaded glands (2 such glands are provided). Threaded glands The unit is also supplied with 2 lead-in holes fitted with plugs. These can be removed as required. -
Page 10: Cable Connections
Installation 2.6 Cable connections 2.6.1 Introduction This chapter covers all necessary external cable connections. IMPORTANT: The following procedure refers to primary installation: 1. Carry out all necessary loop connections. 2. Do not connect up the power before commissioning, see Chap. 4.5. Terminal strip 2 - (internal connections) (detectors) Error output... -
Page 11: External Connection Of 2 Detector Loops - Conventional Version
Installation 2.6.4 External connection of 2 detector loops - conventional version If the unit is connected to a conventional alarm system, the following applies when 2 detector loops (one for each detector) are connected: Terminal strip 1 Loop + 24 V DC + 24 V DC Loop 2 Loop 1... -
Page 12: External Connection Of Detector Loop - Analogue Addressable System
Installation 2.6.6 External connection of detector loop - analogue addressable system If the unit is connected to an analogue addressable fire alarm system the following will apply: Terminal strip 1 Loop + 24 V DC Loop in + 24 V DC (to next detector) 2.6.7 Power supply IMPORTANT:... -
Page 13: Installing The Pipe System
Installing the pipe system 3. Installing the pipe system 3.1 General guidelines Special guidelines apply to agricultural applications.The following general guidelines apply to the installation of the exhaust pipes: 1. The optimum internal diameter of a pipe is 22 mm (the correct size is 25 mm piping). -
Page 14: Guidelines For Agricultural Installations
3.2 Guidelines for agricultural installations For guidelines for agricultural installations, reference is made to the insurance companies’ regulations for fire alarm systems. AutroSense 75 includes among the following: • maximum single pipe length is 46 m •... -
Page 15: Installing The Pipe System In The Roof/Ceiling
Installing the pipe system 3.3 Installing the pipe system in the roof/ceiling To cover a fire zone in a room, the exhaust/suction pipes should be located either directly under the ceiling panels or with a maximum distance of 100 mm to the panels, and laid out in one, two, three or four runs to cover the whole zone area. -
Page 16: Concealed Pipes
Concealed pipes should be secured to ceiling girders or support girders with standard pipe clamps or self-locking clips of nylon. 3.7 Connecting to the AutroSense 75 detector unit The 2 inlets on the top of the detector unit are designed for receiving 25 mm diameter pipes. -
Page 17: Commissioning The System
3. Check that the cables are free from external voltage. 4. If the AutroSense 75 detector unit is connected to a analogue addressable fire alarm system: - check that the interface board and detector is coded to the correct address 5. -
Page 18: Setting Addresses - Analogue Addressable System
Commissioning the system Setting addresses - analogue addressable system • Unscrew the detector cover. The detectors are equipped with 7 address switches marked with the following digital values: 1, 2, 4, 8, 16, 32 and 64. The correct address is found by summing the values of the switches that stand in the OPEN position. -
Page 19: Power Supply
Commissioning the system 4.5 Power supply When all pre-commissioning checks have been completed and the addresses (analogue addressable system only) and switches for air- flow monitoring have been set, then the unit can be connected to the power. • Connect up the 24V DC supply (taken from the external 24V DC outlet on the control panel). -
Page 20: Configuration Of Air-Flow Monitoring
Commissioning the system 4.6 Configuration of air-flow monitoring The air-flow monitoring configuration is an automatic function. This will ensure that the upper and lower air flow limits are correct. 1. Activate the configuration by pressing and holding down for 2 seconds the “LEARN”... -
Page 21: Final Installation Tasks
Commissioning the system 4.7 Final installation tasks • Replace the top cover. IMPORTANT: Ensure that the top cover is replaced correctly to avoid “false” air entering the detector. • Tighten up the 6 screws. Installation & Commissioning Handbook, , P-ASENSE75/IE 980302, 7483 Trondheim Page 19... -
Page 22: Final Testing
Final testing 5. Final testing 5.1 Alarm test / testing of smoke transport time and symmetry • Introduce a puff of smoke (or use an environmentally friendly test gas) into each pipe. • Note the time it takes to give alarm (= smoke transport time). The time lapse should not exceed 120* seconds. -
Page 23: Fire Simulation Test
Final testing 5.3 Fire simulation test To ensure that the aspirating detector functions properly, and to check the integrity of the pipe system, a fire simulation test should be implemented. This test should be as realistic as possible, and the fire should involve the same type of material that can be expected to be found in the monitored fire zones. -
Page 24: Service And Maintenance
Service and maintenance 6. Service and maintenance 6.1 Annual service The service check-list below provides check-points for an annual inspection and service of the system. In seriously polluted environments it may be necessary to inspect and service the system more frequently. Before carrying out a service you should inform the person in charge and, if necessary, disconnect the control outputs. -
Page 25: Changing The Filter
Service and maintenance 6.3 Changing the filter Change the filter as follows: • Loosen the screws and remove the cover. • Remove the filter cover by loosening the 2 screws. • Remove the filter by carefully pulling on the corner. •... -
Page 26: Appendix
7.1 Terminal strip 2 Terminal strip 2 is for connecting internal cables only, and the unit is supplied from Autronica ready-wired. However, when 1 detector loop is connected externally (conventional version), the endload 1 should be removed (terminal strip 2). -
Page 27: Internal Connection Of Detector Loop - Analogue Addressable System
Appendix 7.1.2 Internal connection of detector loop - analogue addressable system Terminal strip 2 Error output (detectors) Loop Detector 1 Detector 2 BNB-35 Installation & Commissioning Handbook, , P-ASENSE75/IE 980302, 7483 Trondheim Page 25... - Page 28 Appendix Installation & Commissioning Handbook, , P-ASENSE75/IE 980302, 7483 Trondheim Page 26...
-
Page 29: Reader's Comments
Please help us to improve the quality of our documentation by returning your comments on this manual: Title: Installation- And Commissioning Handbook, AutroSense 75 Aspirating Detector Ref. No.: P-ASENSE75/IE 980302 Your information on any inaccuracies or omissions (with page reference): Please turn the page Installation &... - Page 30 Fax: --------------------------------------------------------------------------------------------- Date: --------------------------------------------------------------------------------------------- Please send this form to: Autronica Fire and Security AS N-7483 Trondheim Norway Tel: + 47 73 58 25 00 Fax: + 47 73 58 25 01 Installation & Commissioning Handbook, , P-ASENSE75/IE 980302, 7483 Trondheim...
- Page 31 Reader’s Comments Installation & Commissioning Handbook, , P-ASENSE75/IE 980302, 7483 Trondheim...
- Page 32 Autronica Fire and Security AS is an international company, based in Trondheim, Norway and has a world-wide sales and service network. For more than 40 years Autronica Fire ans Security’s monitoring systems have been saving lives and preventing catastrophes on land and at sea. Autronica Fire and Security’s most important business areas are fire detection &...
