Summary of Contents for Wharfedale Pro Typhon Series
- Page 1 Wharfedale Pro Typhon Series User Manual TYPHON-AX12 TYPHON-AX12-BT POWERFUL | PORTABLE | VERSATILE PA WWW.WHARFEDALEPRO.COM...
-
Page 2: Important Safety Instructions
1. IMPORTANT SAFETY INSTRUCTIONS... - Page 3 1.75” voice coil. This is coupled to a 100° x 80° waveguide for smooth HF dispersion. The custom Wharfedale Pro 12” LF transducer has a newly designed ferrite core, uses flat coil windings to aid cooling, and features a moisture rejecting cone material which allows Typhon to be used in damp or humid conditions.
-
Page 4: Important Warnings & Safety Instructions
3. IMPORTANT WARNINGS & SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS – carefully and become familiar with the features and func tions of these products before operating them. RETAIN THESE INSTRUCTIONS – for future reference. COMPLY WITH ALL WARNINGS – All warnings and instructions for this product should be adhered to. - Page 5 4. Typhon-AX12 / Typhon-AX12-BT REAR PANEL FEATURES...
- Page 7 Bluetooth operation (Typhon-AX12-BT only) : a. MONO Mode: Press and release the PAIR button on one speaker only. Select “Wharfedale Pro BT” on your device. The BT LED will change to solid when paired. To disconnect, press and release the PAIR button.
- Page 8 GAIN selection switch A: This switch selects the proper gain structure for INPUT A. If a microphone is connected to INPUT A, use mic mode (up). If the signal source is anything other than a microphone (eg an analogue playback device, keyboard or mixer output) use the line selection (down).
-
Page 9: Technical Drawings
5. TECHNICAL DRAWINGS... -
Page 10: Specifications
6. SPECIFICATIONS Model Name Typhon-AX12 Typhon-AX12-BT System Type Active 12" 2-way Active 12" 2-way Frequency Response (+/-3dB) 55Hz-20kHz 55Hz-20kHz Frequency Range (- 10 dB) 50Hz-20kHz 50Hz-20kHz Maximum SPL(peak)(@1m) 129dB 129dB Sensitivity @ 1W / 1m) 98dB 98dB Low Frequency Transducer Size (mm / inches) 305mm / 12"... - Page 12 2018...
