Wharfedale Pro TYPHON-AXF12 Quick Start Manual

Congratulations on the purchase of your Typhon-AXF 12" active loudspeaker. We take great pride in engineering and building every
Wharfedale Pro product and wish to thank you for entrusting us with your audio. From the time Gilbert Briggs built his first loudspeaker in
1932, to the present day, we have maintained the samestandard of quality in components, workmanship and performance.
Please take the time to read this guide completely in order to get the most from your new loudspeaker.
Your full user manual can also be downloaded from www.wharfedalepro.com
REAR INPUT CONTROLS
1 - Volume controls
2 - DSP setting (4 modes)
3 - DSP selection
4 - Bluetooth operation (BT model only)
5 - Gain selection Input A
6 - Gain selection Input B
7 - 90 Hz Hi Pass Filter switch
TYPHON-AXF12 / AXF12-BT
QUICK START GUIDE
Typhon 12" Monitor Wedge
Typhon 12" models are supplied with a monitor wedge adaptor.
This supplied accessory gives you the perfect angle when using Typhon as a stage monitor.
8 - Power On indicator LED / Limiter LED
9 - Horn LED defeat switch
10 - Power On / Off switch
11 - Output source select
12 - XLR and 1/4" jack inputs
13 - XLR line level output
14 - Power cord input
