Kwikset Kevo Setup

61844 / 01
Bluetooth Enabled Gateway Setup
Bluetooth Enabled Gateway Setup
1
Connect and fully tighten the antenna to the back of the
gateway. Bend the antenna so that it points straight up.
Connect and fully tighten the antenna to the back of the gateway.
Bend the antenna so that it points straight up.
3
Plug the USB cable's power jack end into the gateway. Plug
the USB connector into the power adapter. Plug the power
adapter into a power outlet.
Plug the USB cable's power jack end into the gateway. Plug the USB connector
into the power adapter. Plug the power adapter into a power outlet.
Requirements:
•
Internet service
•
Internet router with
available Ethernet port
•
Active Kevo Plus
membership
2
Plug one end of the Ethernet cable into the gateway.
Plug the other end into your internet router.
Plug one end of the Ethernet cable into the gateway.
Plug the other end into your internet router.
4
Make sure the lights on the gateway are functioning. See the
Light Ring Colors on page 2. Follow the instructions inside the
Kevo app to configure your gateway.
Make sure the lights on the gateway are functioning. See the Light Ring Colors
chart on page 2. Follow the instructions inside the Kevo app to configure your
gateway.
Once configured, you may control the gateway with the Kevo
app or mykevo.com
Once configured, you may control the gateway with the Kevo app or
mykevo.com.
Requirements:
•
Internet service
•
Internet router with
available Ethernet port
•
Active Kevo Plus
membership
©2014 Kwikset Corporation
