- Page 1 INSTALLATION & MAINTENANCE MANUAL HBLS (sensor for HBL fittings) 230 V 50Hz...
- Page 2 These instructions should be read carefully and retained after installation by the end user for future reference and maintenance. These instructions should be used to aid installation of the following product: HBLS (sensor) SAFETY • Installation of this sensor should only be carried out by a qualified electrician or competent person...
- Page 3 Earth – green/yellow Neutral – blue SENSOR SETUP Live – brown (Sensor) (Sensor) Neutral - blue Detection area Detection area can be adjusted from a maxi- Live - brown mum range of 15 meters down to 7 meters by White: Dim - Black: Dim - observing the below settings Switched live – yellow (Sensor) Detection Area Blue: Dim + 100% Red: Dim + Fig 2...
- Page 4 Daylight S10 S11 S12 sensor Disable 200lx 100lx DETECTION DIAGRAM 50lx DETECTION DIAGRAM Ceiling Up to 15m Floor Up to 16m • Switch on power supply and check for correct operation WARNING This product must be disconnected from the circuit if subjected to any high voltage or insulation resistance testing.
