    1747-SDN DeviceNet Scanner Module Catalog Number 1747-SDN, Series D Topic Page Important User Information Safety Guidelines About the 1747-SDN, Series D DeviceNet Scanner Module Before You Begin Install DeviceNet Scanner Module Interpret the LED Indicators Numeric Codes and Descriptions Specifications...

  • Page 2: Important User Information

    1747-SDN DeviceNet Scanner Module Important User Information Solid state equipment has operational characteristics differing from those of electromechanical equipment. Safety Guidelines for the Application, Installation and Maintenance of Solid State Controls (Publication SGI-1.1 available from your local Rockwell Automation sales office or online at http://literature.rockwellautomation.com) describes some important differences between solid state equipment and hard-wired electromechanical devices.
  • Page 3 1747-SDN DeviceNet Scanner Module Follow these guidelines for environment and enclosure information for this equipment. This equipment is intended for use in a Pollution Degree 2 industrial ATTENTION environment, in overvoltage Category II applications (as defined in IEC publication 60664-1), at altitudes up to 2000 m (6562 ft) without derating. This equipment is considered Group 1, Class A industrial equipment according to IEC/CISPR Publication 11.

  • Page 4: About The 1747-Sdn, Series D Devicenet Scanner Module

    Refer to the SLC 500 DeviceNet Scanner Module User Manual, publication 1747-UM655, for additional information on these new enhancements. The 1747-SDN Series D module includes all features provided in the Series C module. The module has the following software and hardware features.
  • Page 5 1747-SDN DeviceNet Scanner Module This feature has the following variations. Module Mode Description Null Contains an empty or disabled scan list (default) Master Serves as a master to one or more slaves but is not simultaneously serving as a slave to another master Slave Serves as a slave to another master...
  • Page 6 1747-SDN DeviceNet Scanner Module Pass-through The SLC 500 pass-through feature allows communication with the DeviceNet network from another network. This feature can be used to adjust and fine tune the nodes on your network. The pass-through feature is not intended to replace a 1770-KFD, 1784-PCD, 1784-PCID, or 1784-PCIDS connection to the network.

  • Page 7: Before You Begin

    1747-SDN DeviceNet Scanner Module Hardware Features Use this illustration to identify the external features of the scanner module. DeviceNet STATUS Module Status indicator MODULE NET Network Status indicator indicates status indicates module status of DeviceNet channel communication link Node address and status displays numeric codes ADDRESS/ERROR and indicates scanner...
  • Page 8 Before you install your module you must know how to: • program and operate an Allen-Bradley SLC 500 programmable controller. • install and configure the devices on your DeviceNet network. Electronic Data Sheet Requirement This release of the scanner module requires the latest EDS file for RSLinx Classic and RSNetWorx for DeviceNet software.

  • Page 9: Install Devicenet Scanner Module

    Manual, publication 1756-QS105. You can update Series A and B scanner modules up to FRN 7.006. Series C IMPORTANT scanner modules support only FRN 8.001 to 8.006. Series D scanner modules support FRN 9.001 and later. Confirm Processor and Adapter Compatibility Make sure that your processor and adapter are compatible.
  • Page 10 1747-SDN DeviceNet Scanner Module 3. Insert the module into the slot you have selected. 4. Apply firm, even pressure to seat the module in the I/O chassis backplane connectors. Connect the Module to the DeviceNet Network To comply with the CE Low Voltage Directive (LVD), DeviceNet must be ATTENTION powered from a source compliant with the following: •...
  • Page 11 1747-SDN DeviceNet Scanner Module WARNING If you connect or disconnect the communications cable with power applied to this module or any device on the network, an electrical arc can occur. This could cause an explosion in hazardous location installations. 2. Connect the DeviceNet drop line to the 10-pin linear plug by matching the wire insulation colors to the colors shown on the label.

  • Page 12: Interpret The Led Indicators

    1747-SDN DeviceNet Scanner Module Apply Chassis Power When you apply chassis power, the module numeric indicators cycle through the following displays. DeviceNet Module Numeric STATUS Indicators MODULE NET ADDRESS/ERROR • Seven-segment lamp test (88) • Firmware major revision (01…7F hexadecimal) •...
  • Page 13 1747-SDN DeviceNet Scanner Module The DeviceNet channel has a bicolor (green/red) network status indicator (NET). The following table provides troubleshooting information about the DeviceNet channel communication link. DeviceNet Channel Communication Indicator Description Device Operation Corrective Action Color The channel is disabled for The device has no power or Power-up the module, provide DeviceNet communication.

  • Page 14: Numeric Codes And Descriptions

    1747-SDN DeviceNet Scanner Module Numeric Codes and Descriptions Your module uses numeric displays to indicate diagnostic information about the status of your module. The display flashes at 1-second intervals. The following table summarizes the meanings of the numeric codes. Numeric Description Corrective Action Code...
  • Page 15 1747-SDN DeviceNet Scanner Module Numeric Description Corrective Action Code Error detected in sequence of fragmented I/O Check scan list table entry for slave device to messages from device. make sure that input and output data lengths are correct. Check slave device configuration. Slave device is returning error responses when Check accuracy of scan list table entry.

  • Page 16: Specifications

    1747-SDN DeviceNet Scanner Module Numeric Description Corrective Action Code Unrecoverable firmware failure. Service or replace your module. Unrecoverable hardware failure. Service or replace your module. RAM Test Failure Service or replace your module. Lost power during FLASH upgrade Service or replace your module. No application code Service or replace your module.
  • Page 17 1747-SDN DeviceNet Scanner Module SLC DeviceNet Scanner — 1747-SDN Attribute Value Emissions CISPR 11: Group 1, Class A (with appropriate enclosure) ESD immunity IEC 61000-4-2: 6 kV contact discharges 8 kV air discharges Radiated RF immunity IEC 61000-4-3: 10 V/m with 1 kHz sine-wave 80% AM from 80…2000 Mhz EFT/B immunity IEC 61000-4-4: +2 kV at 5 kHz on communication ports...

  • Page 18: Additional Resources

    1747-SDN DeviceNet Scanner Module Certifications - 1747-SDN Certification (when product is Value marked) c-UL-us UL Listed Industrial Control Equipment, certified for US and Canada. See UL File E113724. UL Listed for Class I, Division 2 Group A, B, C, D Hazardous Locations, certified for US and Canada.

  • Page 19: Publication 1747-In058F-En-P - December

    1747-SDN DeviceNet Scanner Module North American Hazardous Location Approval The following information applies when Informations sur l’utilisation de cet operating this equipment in hazardous équipement en environnements locations: dangereux: Products marked "CL I, DIV 2, GP A, B, C, D" are Les produits marqués "CL I, DIV 2, GP A, B, C, D"...
  • Page 20 Please contact your local Rockwell Automation representative for the return procedure. Rockwell Auotmation, Allen-Bradley, TechConnect, SLC, SLC 500, SLC 5/02, SLC 5/03, SLC 5/04, SLC 5/05, RSLinx, RSLogix 500, and RSNetWorx are trademarks of Rockwell Automation, Inc. Trademarks not belonging to Rockwell Automation are property of their respective companies.
