Code 3 RLS 3997 Installation & Operation Manual page 22

Push Button Switch Control Head, Parts List
Ref No. Description
1 8 - 32 x 1/4" Machine Screw
2 Knob, Rectangular
3 4 - 40 x 3/8", Pan Hd Phil, Black Oxide
4 Switch Actuator Keypad, 1x6, Silicone Rubber
5 Enclosure, Control Head, RLS Siren
6 Standoff, 4 - 40 x .75"
7 Label, Faceplate, Model 3998
8 Label, Faceplate, Model 3999
9 Label, Configuration (Part of Wiring Label)
1 0 1/4 - 20 x .375", Hex Washer Hd, Zinc
1 1 Switch Actuator, Small Arc, RLS Sirens
1 2 Switch Actuator, Large Arc, RLS Sirens
1 3 Switch Actuator, Oval, RLS Sirens
1 4 Switch Actuator, Rectangular, RLS Sirens
1 5 Bracket, Control Head, RLS Sirens
1 6 Switch Assembly w/Harness
1 7 E-Tray, Control Head, RLS Sirens
1 8 PCB Assembly, Control Head,
Model 3998
Models 3997 & 3999
2 2
Part No. Qty.
T 0 1 3 8 5 2
T 0 1 9 1 7 1
T 0 6 9 3 7 7
T 1 0 8 7 8 1
T 1 0 8 8 0 1
T 1 0 8 9 0 2
T 1 0 9 0 1 1
T 1 0 9 0 2 1
T 1 0 9 0 4 1
T 1 0 9 1 2 2
T 1 0 9 1 3 2
T 1 0 9 1 4 2
T 1 0 9 1 5 3
T 1 0 9 1 6 2
S 7 1 5 2 8 2
S 5 5 2 2 9 1
S 7 1 5 3 1 1
1
S 7 1 5 5 2
S 7 1 5 6 2
