The following antennas have been approved for use with a SCALANCE W7x8:
Type
ANT792-6MN
ANT793-6MN
ANT792-8DN
ANT793-8DJ
ANT793-8DK
ANT793-8DP
ANT793-6DT
ANT795-6DC
ANT793-6DG
ANT795-6MN
ANT795-6MT
ANT795-4MC
ANT795-4MD
ANT795-4MA
ANT792-4DN
SCALANCE W788C-2
Operating Instructions, 11/2014, A5E03692120-07
Properties
Omni antenna, mast/wall mounting, 6 dBi
2.4 GHz, N-Connect female
Omni antenna, mast/wall mounting, 5 dBi
5 GHz, N-Connect female
Directional antenna, mast/wall mounting,
14 dBi
2.4 GHz, N-Connect female
Directional antenna, mast/wall mounting,
18 dBi
5 GHz, 2 x N-Connect female
Directional antenna, mast/wall mounting,
23 dBi
5 GHz, 2 x N-Connect female
Directional antenna, mast/wall mounting,
13 / 13.5 dBi
4.9 GHz and 5 GHz, N-Connect female
Wide angle antenna (MIMO), mast/wall
mounting, 8 dBi
5 GHz, 3 x QMA connector female
Wide angle antenna, mast/
wall mounting, 9 dBi
2.4 GHz and 5 GHz, N-Connect female
Wide angle antenna, mast/
wall mounting, 9 dBi
5 GHz, 2 x N-Connect female
Omni antenna, mounted on roof/vehicle,
6/8 dBi
2.4 GHz and 5 GHz, N-Connect female
Omni antenna (MIMO), mounted on
roof/vehicle/ceiling, 5/7 dBi
2.4 GHz and 5 GHz, 3 x QMA connector
female
Omnidirectional antenna, 3/5 dBi, 2.4 GHz
and 5 GHz, IP65, N-Connect male for
direct installation on the device, straight
connector.
Omnidirectional antenna, 3/5 dBi, 2.4 GHz
and 5 GHz, IP65, N-Connect male for
direct installation on the device, 90° con-
nector.
Omni antenna, directly on the device, 3/5
dBi
2.4 GHz and 5 GHz, IP30, R-SMA con-
nector male for direct mounting on the
device, connector angle adjustable 0° to
180°.
RCoax helical antenna, circular polariza-
tion, 4 dBi, 2.4 GHz, N-connect female.
5.4 Suitable antenna cables and antennas
Order number
6GK5 792-6MN00-0AA6
6GK5 793-6MN00-0AA6
6GK5 792-8DN00-0AA6
6GK5 793-8DJ00-0AA0
6GK5 793-8DK00-0AA0
6GK5793-8DP00-0AA0
6GK5 793-6DT00-0AA0
6GK5 795-6DC00-0AA0
6GK5 793-6DG00-0AA0
6GK5 795-6MN10-0AA6
6GK5 795-6MT00-0AA0
6GK5 795-4MC00-0AA3
6GK5 795-4MD00-0AA3
6GK5 795-4MA00-0AA3
6GK5 792-4DN00-0AA6
Connection
25
