- Page 1 Total 50W 36 Inches Stereo TV Sound Bar System DS6X Series Model: DS6201/6301/6401/6501/6601/6701 DS6202/6302/6402/6502/6602/6702 DS6203/6303/6403/6503/6603/6703 DS6205/6305/6405/6505/6605/6705 User Manual...
-
Page 2: Table Of Contents
Table of Contentss Important Notes --------------------------------------------------------------------------------- 1 Important Safety Instructions ----------------------------------------------------------------- 2 Safety instructions -------------------------------------------------------------------------- 2 Battery precautions ------------------------------------------------------------------------- 3 FCC information ----------------------------------------------------------------------------- 4 Package Contents ------------------------------------------------------------------------------ 5 Features and Specifications ------------------------------------------------------------------ 6 System Overview i------------------------------------------------------------------------------- 7 Front view ii------------------------------------------------------------------------------------ 7 Connector panel i---------------------------------------------------------------------------- 7 Remote control ii----------------------------------------------------------------------------- 8 Setting Up the System... -
Page 3: Important Notes
Important Notess Before using the TV sound bar system, please read the following important notes. Please read this user manual carefully and save it for future reference. For optical and coaxial cable connection, change your source device’s audio output setting to “PCM” format . Refer to your source device’s user manual for more information. -
Page 4: Important Safety Instructions
Important Safety Instructionss Do not make unauthorized alterations to the system, doing so may compromise safety, regulatory compliance, and may void the warranty. This system contains magnetic material, contact your physician if you have questions on whether this might affect the operation of your implantable medical device. -
Page 5: Battery Precautions
Important Safety Instructionss ithe use of the system by a person responsible for their safety. 12. Children should be supervised to ensure that they do not play with the system. 13. This system is classified as protection class II and must not be connected to a protective ground. -
Page 6: Fcc Information
Important Safety Instructionss Do not mix different types of batteries together ( e.g: Alkaline and Carbon-zinc) or old batteries with fresh ones. If the batteries in the device are consumed or the device is not to be used for a long period of time, remove the batteries to prevent damage or injury from possible leakage. -
Page 7: Package Contents
Package Contentss 1 X Sound bar Accessories: 1 X Power adapter 1 X User manual 1 X Remote control 1 X Optical cable 1 X Coaxial cable 1 X Audio cable (RCA to RCA) 1 X Audio cable (stereo 1/8 inch(3.5mm) to RCA) 2 X Wall mount brackets 4 X Wall anchors 4 X Screws (M4 X 30mm) -
Page 8: Features And Specifications
Features and Specificationss Features Total 50 W power usage 36 inches TV sound bar 2.0 Channel two way speaker system 6 speaker drivers (4 woofer and 2 tweeter) Analog audio interface (AUX input) Digital audio interface (optical input and coaxial input) Stream music from smart phone or tablet The sound bar system can be mounted on the wall Full function infrared remote control... -
Page 9: System Overview I
System Overviews Front view 6 7 8 9 10 Buttons 1. Mode (Source) 2. Play / Pause 3. Power（Standby） 4. Volume down 5. Volume up Source indicators 6. OPT (Optical) 7. COAX (Coaxial) 8. Power（Standby） 9. BT (Bluetooth) 10. AUX (Auxiliary) 11. -
Page 10: Remote Control Ii
System Overviews Remote control Buttons 20. Power 21.Bluetooth 22. HDMI 23. Volume + 24. Previous 25. Play pause / mute 26. Next 27. Volume－ 28. Movie 29. Music 30. News 31. Optical 32. Coaxial 33. AUX / boost Note: HDMI button is only for the HDMI converter (not supplied). 8 –... -
Page 11: Setting Up The System
Setting Up the Systems Unpacking Remove all packaging. Check for the presence of all parts and for transport damage. In case of damage or incomplete delivery, please contact your dealer. Please keep the packaging. The system can be stored in it, if not used for a longer period of time. -
Page 12: Wall Mounting
Setting Up the Systems Caution! Make sure the power adapter is disconnected from the electrical outlet before making any mounting and connection. During operation, if the cables require to be reconnected, the power adapter must be disconnected first, otherwise damage to the system may result. -
Page 13: Optical And Coaxial Cable Connection I
Setting Up the Systems Optical and coaxial cable connection Use the supplied optical cable or coaxial cable to connect the sound bar to a TV, DVD, Blu-Ray Player or other suitable devices. Connect one end to the optical or coaxial out socket of the TV, DVD, Blu-Ray Player or other suitable devices. -
Page 14: Audio Cable Connection 1
Setting Up the Systems Audio cable connection 1 Use the supplied RCA to RCA audio cable to connect the sound bar to a TV, DVD, Blu-Ray Player or other suitable devices. Connect one end to the headphone or line out socket of the TV, DVD, Blu-Ray Player or other suitable devices. -
Page 15: Audio Cable Connection
Setting Up the Systems Audio cable connection 2 If your TV or other source device only has a headphones socket, use the supplied stereo 1/8 inch (3.5mm) to RCA audio cable to connect the sound bar to your TV or other source devices. -
Page 16: Using The Remote Control I
Using the systems Using the remote control >>> Inserting/replacing batteries 1. Slide to open the battery compartment cover. 2. Insert 2 X 1.5V AAA batteries (not supplied) into the battery compartment. Match the polarity markings in the battery compartment. 3. Close the battery compartment cover. Caution! The sound bar can only work with the remote control package included, not compatible with universal remote control. -
Page 17: Using The System I
Using the systems Using the remote control >>> Remote control operation range: Remote sensor Approx. 16.5 feet (5 meters) 30 degree 30 degree Notes: When there is an obstacle between the remote sensor of the sound bar and the remote control, the remote control may not operate When direct sunlight, an incandescent lamp, fluorescent lamp or any other strong... -
Page 18: Get Power And Started I
Using the Systems Get power and started Make sure all the source connections are made properly before you connect the power adapter. Plug the power adapter to the DC IN socket, then to a suitable electrical outlet. The power indicator lights up red. Indicating the sound bar is in standby mode. Turning off your TV speakers: To avoid hearing distorted sound, turn off your TV speakers. -
Page 19: Basic Functions
Using the Systems Basic functions >>> Selecting a source You can have several source devices connected permanently to the sound bar. Available sources are: OPT / COAX / BT / AUX Source Function Optical , connection with an optical fiber cable. COAX Coaxial, connection with a coaxial cable. -
Page 20: Bluetooth Function
2. Activate the Bluetooth function of the external device and search for Bluetooth devices. 3. Select Sine Audio from the Bluetooth device list. 4. Follow the instructions shown on your device’s screen. 5. When the Bluetooth connection is established, files from your connected Bluetooth device will be played through the sound bar. -
Page 21: Troubleshooting
Troubleshootings Problem Solution No power Check the power adapter is properly connected to an electrical outlet. Check the DC plug is properly connected to the DC IN socket. Unplug the power adapter for at least one minute and reconnect. No Sound Press the Power button on the sound bar or remote control to turn on the sound bar. - Page 22 Ensure you are using the correct device. If the device is still not connected, try the following: Remove the sound bar (Sine Audio) from the list of “paired devices” on your phone/tablet. Turn the sound bar off and then on again.
-
Page 23: Care And Maintenance I
The following are excluded from the Sine Audio warranty coverage: Product over warranty. - Page 24 Ten years, just for original sound English - V1.0 Printed in China (2018)
Need help?
Do you have a question about the DS6X Series and is the answer not in the manual?
Questions and answers
No sound when turned on got double beep. How do you fix?
To fix the no sound and double beep issue on the Sine Audio DS6X Series, follow these steps:
1. Check TV Speakers: Turn off your TV speakers to avoid distorted sound. Refer to your TV's user manual for instructions.
2. Power On Sound Bar: Press the Power button on the sound bar or remote control. Ensure the power indicator lights up green.
3. Check Audio Source: Ensure sound is coming from the sound bar.
4. Adjust Volume: Set the sound bar's volume to 75% of its maximum level and adjust the source device's volume to a suitable level.
5. Select Sound Mode: Choose an appropriate sound mode (Movie, Music, or News) using the remote control for better audio processing.
6. Check Connections: Ensure audio cables are properly connected and fully inserted.
7. Bluetooth Troubleshooting: If using Bluetooth, bring the device closer, remove obstacles, and ensure the sound bar is not connected to another Bluetooth device.
8. Reset Sound Bar: Unplug the power adapter for at least one minute, then reconnect.
These steps should resolve the issue.
This answer is automatically generated
When switched on red goes to blue then there is a beep and the blue light flashes.....no sound. Have switched off and restarted but just the same.
I have vibration in the sound bar can we open to see what vibrate? Richard (tvq@videotron.ca)
I want to stop the commentaries when using the soundbar..
