2.3 EQUIPMENT CONSTITUTION

MU consists of the following parts:
Module Description
Master Unit Chassis includes eight slots for RF Unit, two slots for Fiber Optical Unit,
MU01-RACK
and one slot for Power Supply Unit.
iDAS Master Unit Power Supply Unit (PSU) converts the input voltage into stable
MU01-PSU
DC to supply power for other modules of Master Unit.
Master Unit Fiber Optical Unit (FOU) completes optical signal and RF signal
MU01-FOU conversion. One FOU has four optical ports, which means each FOU can support
up to four RUs.
Master Unit RF Unit completes separation and combination of uplink and downlink
MU01-RFU
signal with independent gain control, supports either simplex or duplex.
RU consists of the following parts:
Module Description
Remote Unit; A module design which supports 4 bands, including 2300MHz,
HRU01-6900
2300MIMO, 2500MHz, 2500MIMO.
ENU STATUS : 1-0-0
USER MANUAL FOR COMFLEX-6900
Table 1: MU Components
Table 2: RU Components
