HEIN-WERNER AUTOMOTIVE HW93737A Operating Instructions & Parts Manual

Portable air jack
Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
Portable Air Jack
Operating Instructions & Parts Manual
Model Number
HW93737A
!
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
Read this manual and follow all the Safety Rules and Operating Instructions before using this product.
HW93737A-M0 rev 09/07
Capacity
10 Ton
816-891-6390 customerservices@heinwerner-automotive.com
10939 N. Pomona Ave. Kansas City, MO 64153
Made in the
U.S.A.
SFA Companies

Advertisement

Table of Contents
loading

Related Manuals for HEIN-WERNER AUTOMOTIVE HW93737A

Summary of Contents for HEIN-WERNER AUTOMOTIVE HW93737A

  • Page 1 Obey all safety messages that follow this symbol to avoid possible injury or death. SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153 816-891-6390 customerservices@heinwerner-automotive.com Read this manual and follow all the Safety Rules and Operating Instructions before using this product. HW93737A-M0 rev 09/07...

  • Page 2: Safety And General Information

    Power Jack Size Air Pressure for Weight Height Height Travel ( L x W x H ) Rated Capacity HW93737A 10 Ton 17 3/4" to 40" 51 1/2" 11 1/2" 22" x 12" x 17" 200 psi 165 lb. Saddle...
  • Page 3 WARNING • Study, understand, and follow all printed materials provided with/on this product before use. • Do not exceed rated capacity. Rated capacity does NOT increase with the use of multiple jacks. • Use only on hard, level surfaces capable of supporting rated capacity loads. •...

  • Page 4: Operation

    OPERATION Lifting Only attachments and/or adapters supplied by the manufacturer shall be used. Lift only on areas of the vehicle as specified by the vehicle manufacturer. 1. Follow the vehicle manufacturer’s recommended guidelines for lifting. 2. Position vehicle on hard level surface with parking brakes "ON". Chock wheels at opposite end. When lifting trailers, lower landing gear.
  • Page 5 Lowering Be sure all tools and personnel are clear before lowering load. Maintain control of the rate of speed at which the load lowers at all times! 1. Push the air valve lever towards air input to apply air pressure slowly with lock pin still engaged. 2.

  • Page 6: Maintenance

    MAINTENANCE Inspections should be made before each use of jack, checking for abnormal conditions. Regular inspections should be made weekly for daily use and monthly for intermittent use. 1. Inspect air hose for leaks or kinks. Replace if necessary. 2. Air control valve should operate freely. Wheels should rotate freely. 3.

  • Page 7: Replacement Parts

    Bushing 737-002-015 Cylinder Cap 737-002-005 Washer 737-002-016 Grip 737-002-006 737-002-017 Handle 737-002-007 Saddle 737-002-018 737-002-008 Ring 737-002-019 Air Hose 737-002-009 737-002-020 Valve 737-002-010 Seal 737-002-021 Bolt 737-002-011 Washer 737-002-022 Ram Wear Guide Figure 4 - Parts Illustration for Model HW93737A...

  • Page 8: Two Years Limited Warranty

    TWO YEARS LIMITED WARRANTY For a period of two (2) years from date of purchase, SFA Companies will repair or replace, at its option, without charge, any of its products which fails due to a defect in material or workmanship under normal usage. This limited warranty is a consumer's exclusive remedy.
