Supplied accessories

Make sure the following accessories are provided with the product.
Remote control "AA" size battery
unit (X1) (X2)
Page 9 Page 9
NOTE
• Always use the AC cord supplied with the TV/DVD.

QUICK REFERENCE

Attaching the stand

• Before attaching (or detaching) the stand, unplug the AC cord from the AC input terminal.
• Before performing work spread cushioning over the base area to lay the TV on. This will prevent it from being damaged.
CAUTION
• Attach the stand in the correct direction.
• Be sure to follow the instructions. Incorrect installation of the stand may result in the TV falling over.
Confirm the 8 screws supplied with the TV.
1
Short screws ( 4)
X
(used in step 2)
2
Remove the covering sheet of the stand.
Set the post for the stand unit onto the box.
1
Attach the base to the post.
2
Attach the base to the 4 screws into the 4
3
holes on the bottom of the base.
Hex key
Screw
AC cord Cable Clamp
(X1) (X1)
Page 8 Page 8
Long screws ( 4)
X
(used in step 3)
• To detach the stand, perform the step in reverse order.
Cloth Stand unit
(X1)
Page 7
Page 8
3
Insert the stand into the openings on the
1
bottom of the TV.
Insert and tighten the 4 screws into the 4 holes
2
on the rear of the TV.
4
For protection, sheets are covering the product.
Please remove these sheets before use.
NOTE
LC-26DV22U
LC-26DV22U-W
LC-32DV22U
COMBINATION LIQUID CRYSTAL
TELEVISION AND DVD/CD PLAYER
COMBINÉ TÉLÉVISEUR ACL ET
LECTEUR DVD/CD
COMBINACION TELEVISOR CON PANTALLA
DE CRISTAL LÍQUIDO CON DVD/DISCOS COMPACTOS
OPERATION MANUAL
MODE D'EMPLOI
MANUAL DE OPERACIÓN
1
Products that have earned the ENERGY STAR ® are designed to protect the environment through
superior energy efficiency.
®
Les produits agréés ENERGY STAR sont conçus pour protéger l'environnement par un rendement
énergétique supérieur.
Los productos que han ganado la marca ENERGY STAR ® han sido diseñados para proteger el medio
ambiente mediante una eficiencia superior en el uso de la energía.
Operation
(X1) manual (X1)
Hex key
Screw
Soft cushion
7
