Connecting a PC (personal computer)
Picture and Audio adjustments in
PC mode
There are a number of picture settings you can adjust
to optimize the performance of the unit in PC mode.
1
Press TV MENU during PC mode.
PC monitor menu will appear.
2 Press / to select
(AUDIO).
BRIGHTNESS
CONTRAST
HOR POSITION
VER POSITION
PHASE
CLOCK
:SELECT
3
Press / to select a specific adjustment
item.
4
Press / to adjust the setting.
5
Press EXIT to return to the normal screen.

PC compatibility chart

PC/MAC Resolution Frequency
640 x 400
720 x 400
VGA
640 x 480
WVGA 848 x 480
PC
SVGA 800 x 600
XGA 1,024 x 768
1,280 x 720
WXGA 1,280 x 768
1,360 x 768
SXGA 1,280 x 1,024
MAC 13" VGA 640 x 480
MAC 16" SVGA 832 x 624
MAC 19" XGA 1,024 x 768
NOTE
• The numerical values of resolutions and frequencies
mentioned above are standard.
They may differ from the values when actually displayed.
(PICTURE) or
25
50
25
25
0
0
:ADJUST
Horizontal Vertical
Frequency Compatible
(kHz) (Hz)
31.5 60
37.9 85
31.5 60
31.5 70
37.9 85
31.5 60
37.9 72
37.5 75
43.3 85
31.0 60
35.1 56
37.9 60
48.1 72
46.9 75
53.7 85
48.4 60
56.5 70
60.0 75
68.7 85
44.8 60
47.8 60
48.1 60
47.7 60
64.0 60
34.9 67
49.7 75
60.2 75
Picture Adjustment
Selected Item Description
BRIGHTNESS To adjust the brightness of PC Monitor
screen.
CONTRAST To adjust the contrast of PC Monitor screen.
HOR POSITION To adjust the horizontal position of the
image on the PC Monitor screen. Each video
standard will require a different value for this
setting.
VER POSITION To adjust the vertical position of the image on
the PC Monitor screen. Each video standard
will require a different value for this setting.
PHASE This must be adjusted after the frequency has
been set optimize picture quality.
CLOCK To minimize any vertical bars or stripes visible
on the screen background.
RED/GREEN/ To adjust the color temperature of the PC
BLUE Monitor screen.
WXGA INPUT Set to ON, when you select the WXGA mode
on the PC.
BACK To adjust the screen brightness for
LIGHTING improved picture clarity.
Audio Adjustment
Selected Item Description
BASS Press or
TREBLE Press or
BALANCE Press or
from both speakers.
SURROUND Press or
effect.
NOTE
• If no buttons are pressed for more than approx. 60
seconds, the PC Monitor Menu screen will return to
normal Monitor screen automatically.
• The PC Monitor Menu settings are not effective for normal
TV mode or external input modes.
NOTE
• For resetting all Picture adjustment items or Audio
adjustment items to the factory preset values, press /
to select "RESET", and then press / .
Factory settings;
Picture adjustment:
BRIGHTNESS ................................................ center (25)
CONTRAST ..............................................maximum (50)
RED/GREEN/BLUE ........................................ center (25)
Audio adjustment:
BASS/TREBLE ............................................... center (25)
BALANCE ......................................................... center(0)
to adjust the bass sound.
to adjust the treble sound.
to obtain an equal sound level
to turn on or off the surround
