TEKTELIC Communications T0004437 User Manual

Pearl gateway
Table of Contents

Advertisement

Available languages

Available languages

Quick Links

TEKTELIC C
Document type:
Document number:
Document version:
Document Status:
Product name:
Product codes:
TEKTELIC Communications Inc.
th
7657 10
Street NE
Calgary, AB, Canada T2E 8X2
Phone: (403) 338-6900
© 2017 TEKTELIC Communications Inc., All rights reserved.
All products, names and services are trademarks and registered trademarks of their respective companies.
Disclaimer:
Material contained in this document is subject to change without notice. The material herein is solely for
information purposes and does not represent a commitment by TEKTELIC or its representatives. TEKTELIC has
prepared the information contained in this document solely for use by its employees, agents, and customers.
Dissemination of this information and/or concepts to other parties is prohibited without the prior written consent
of TEKTELIC. In no event will TEKTELIC be liable for any incidental or consequential damage in connection with the
furnishing, performance or use of this material.
TEKTELIC reserves the right to revise this publication in accordance with formal change control procedures defined
by TEKTELIC.
OMMUNICATIONS
User Manual
T0004906
1.6
Approved
Pearl Gateway
T0004437, T0004438, T0004372
I
.
NC

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T0004437 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for TEKTELIC Communications T0004437

  • Page 1 Street NE Calgary, AB, Canada T2E 8X2 Phone: (403) 338-6900 © 2017 TEKTELIC Communications Inc., All rights reserved. All products, names and services are trademarks and registered trademarks of their respective companies. Disclaimer: Material contained in this document is subject to change without notice. The material herein is solely for information purposes and does not represent a commitment by TEKTELIC or its representatives.
  • Page 2 Mobile GW 5V antenna output June 16, 2017 Draft S. Morrison Updates to clarify mounting procedure June 07, 2017 Draft S. Morrison Initial release Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 2 of 52...
  • Page 3: Table Of Contents

    Équipement requis pour l'installation ................41 Montage Pearl Gateway ....................41 Montage Pearl TTU......................43 Installation par câble à la terre ..................46 Installation du câble d'alimentation CC ................. 49 Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 3 of 52...
  • Page 4 Installation du câble RF ....................51 Déclarations de conformité radio ..................52 Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 4 of 52...
  • Page 5: Product Description

    Both Gateways support an active GPS antenna which is powered through the GPS antenna feed from the Gateway. The GPS antenna feed is protected against overload conditions and short circuit conditions with an internal auto-resetting protection circuit. Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 5 of 52...
  • Page 6 The Fixed Gateway also contains binary alarm inputs for site management. Figure 1 illustrates Mobile Gateway while Figure 2 illustrates the Fixed Gateway. Figure 1: Pearl Mobile Gateway Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 6 of 52...
  • Page 7: External Interfaces

    Front plastic connector ( CPC) p/n 33000111-02 or equivalent Industry standard single hole lug for #8- Front Screw with lug Chassis (Earth) Ground 32 screw Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 7 of 52...
  • Page 8 Industry standard USB type B plug Ethernet Front RJ-45 socket Industry standard RJ-45 plug Industry standard single hole lug for #8- Chassis (Earth) Front Screw with lug 32 screw Ground Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 8 of 52...
  • Page 9 DC power Chassis Site alarms USB-A USB-B & alarms ground Front Bulkhead GPS antenna ISM antenna Rear Bulkhead Figure 4: Pearl Fixed Gateway Module Interconnect Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 9 of 52...
  • Page 10 Bottom N-type female Industry standard N-type male interface Port Industry standard single hole lug for #8- Chassis (Earth) Bottom Screw with lug 32 screw Ground Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 10 of 52...
  • Page 11 IMS antenna port Chassis Fixed Gateway ground Module interface Bottom Figure 5: Pearl TTU Module Interconnect Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 11 of 52...
  • Page 12: Specifications

    Relative Humidity Maximum 2,000 m (6,560 ft) Operating Altitude 12V DC nominal DC Power Input 10V to 15V DC operating range +/-16V DC no damage Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 12 of 52...
  • Page 13 Maximum 3,048 m (10,000 ft) Operating Altitude 20kV, 1.2/50us combination waveform Surge protection IP67 Weather Tightness CSA/UL 60950-1 & & CSA/UL 60950-22 Regulatory Compliance FCC Pt. 15 Class B Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 13 of 52...
  • Page 14 This radio transmitter (Mobile Gateway IC: 22504-T0004437, Fixed Gateway IC: 22504- T0004438) has been approved by Industry Canada to operate with the antenna types listed below with the maximum permissible gain indicated. Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device.
  • Page 15: Installation

    20 A. The overcurrent protection must have the appropriate current interrupt capacity for the power source and must be incorporated into the non-earthed conductor(s) of the DC supply. Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 15 of 52...
  • Page 16: Unpacking And Inspection

    Mounting the Gateway module requires access to both sides of the mounting surface; this may require two persons in cases where the mounting surface is large. Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 16 of 52...
  • Page 17 136 kg (300 lbs). Ensure sufficient free space around the bulkhead connectors for access and cable ingress. Figure 6: Pearl Mobile Gateway Module Mounting Points Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 17 of 52...
  • Page 18: Pearl Ttu Mounting

    Figure 8 and Figure 9. The M8 bolts shall be selected according to the site specific mounting surface material and shall include locking hardware. Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 18 of 52...
  • Page 19 Ensure sufficient free space around the bulkhead connectors for access and cable ingress. 2 x M5 x 0.8, max. 10mm 4 places Figure 8: TTU Module Mounting Points Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 19 of 52...
  • Page 20 Slot for pole strap 4 places M8 screw or bolt 4 places Figure 9: TTU Module Mounting with Small Brackets Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 20 of 52...
  • Page 21: Ground Cable Installation

    The Pearl Gateway grounding system shall follow local and national electrical codes. The Protective Earth Ground conductor terminated at the ground lug point is mandatory and must Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 21 of 52...
  • Page 22 4. Install the ground cable with its screw lug onto the chassis ground point using a #8-32 screw with flat and star lock washers, torqued to 2.2 Nm (20 in·lbs). #8-32 Figure 11: Pearl Mobile Gateway Module Ground Point Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 22 of 52...
  • Page 23 #8-32 Figure 12: Pearl Fixed Gateway Module Ground Point Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 23 of 52...
  • Page 24: Dc Power Cable Installation

    DC power is supplied to the Mobile Gateway Module through a two pin circular plastic connector (CPC). The mating CPC connector shall be as specified in Table 1-2 and shall follow the polarity identified in Figure 14. Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 24 of 52...
  • Page 25 The mating connector shall be as specified in Table 1-3 and shall follow the signal assignment identified in Figure 15. DC Positive DC Negative Pin 5 Pin 6 Figure 15: Fixed Gateway Module DC Power Connector Signals Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 25 of 52...
  • Page 26: Rf Cable Installation

    TEKTELIC recommends taping with Scotch Wireless Weatherproofing Kit, WK-101. Follow the taping procedures outlined by the supplier of this tape system. Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 26 of 52...
  • Page 27: Radio Compliance Statements

    Only antenna with maximum gain of 5dBi can be used for the mobile gateway (tested). Only antenna with a maximum gain of 8dBi can be used for the fixed gateway. Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 27 of 52...
  • Page 28 The IC label shall be visible from the outside of the end product, or the host device shall bear a second label stating: “Contains IC: 22504-T0004438”. Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 28 of 52...
  • Page 29: Description Du Produit

    RF. L'alimentation de l'antenne RF Gateway est protégée contre les conditions de surcharge et les conditions de court-circuit avec un circuit de protection interne auto-réinitialisation. Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 29 of 52...
  • Page 30 La passerelle fixe contient également des entrées d'alarme binaires pour la gestion du site. La figure 1 illustre la passerelle mobile tandis que la figure 2 illustre la passerelle fixe. Figure 16: Pearl Mobile Gateway Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 30 of 52...
  • Page 31: Interfaces Externes

    Connecteur standard USB type A de USB-A De face Récepteur USB type A l'industrie Connecteur standard USB type B de USB-B De face Récepteur USB type B l'industrie Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 31 of 52...
  • Page 32 DC Power & alarms De face Molex Mini-fit 2x3 header Molex Mini-fit 2x3 plug Site Alarms De face Molex Mini-fit 2x4 header Molex Mini-fit 2x4 plug Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 32 of 52...
  • Page 33 Ethernet De face RJ-45 socket Fiche technique standard RJ-45 De face Visser avec patte Patte standard unique pour la vis # 8-32 Châssis Terre Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 33 of 52...
  • Page 34 Ethernet DC power Châssis Site alarms USB-A USB-B & alarms Terre de face ISM antenna GPS antenna arrière Figure 19: Pearl Fixed Gateway Module Interconnect Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 34 of 52...
  • Page 35 Gateway module SMA jack Fiche SMA standard de l'industrie interface Port Chassis (Earth) Visser avec patte Patte standard unique pour la vis # 8-32 Ground Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 35 of 52...
  • Page 36 IMS antenna port haut Châssis Fixed Gateway Terre Module interface Figure 20: Pearl TTU Module Interconnect Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 36 of 52...
  • Page 37: Specifications

    -40°C to 70°C (-40°F to 158°F) Niveau ambiant au niveau de la mer, y Température compris le chargement solaire d'utilisation 10% to 100% Humidité relative Altitude de Maximum 2,000 m (6,560 ft) fonctionnement Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 37 of 52...
  • Page 38 Maximum 3,048 m (10,000 ft) fonctionnement 20kV, 1.2/50us combination waveform Surge protection IP67 Weather Tightness CSA/UL 60950-1 & & CSA/UL 60950-22 Regulatory Compliance FCC Pt. 15 Class B Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 38 of 52...
  • Page 39 Cet émetteur radio (Mobile Gateway IC: 22504-T0004437, IC de la passerelle fixe: 22504- T0004438) a été approuvé par Industrie Canada pour fonctionner avec les types d'antennes énumérés ci-dessous avec le gain maximal admissible indiqué. Les types d'antenne non inclus dans cette liste, ayant un gain supérieur au gain maximal indiqué pour ce type, sont strictement interdits pour être utilisés avec cet appareil...
  • Page 40: Installation

    • La passerelle Pearl doit être fournie par un dispositif de protection contre les surintensités d'entrée d'au plus 20 A. La protection contre les surintensités doit avoir la capacité Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 40 of 52...
  • Page 41: Déballage Et Inspection

    Le motif de forage de forage est sur un carré comme indiqué sur la figure 6 et la figure 7. La taille de l'aneth doit être sélectionnée pour un léger jeu sur les vis M4. Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 41 of 52...
  • Page 42 Assurez-vous un espace libre suffisant autour des connecteurs de cloisons pour l'accès et l'entrée des câbles. Figure 21: Points de montage du module de passerelle mobile Pearl Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 42 of 52...
  • Page 43: Montage Pearl Ttu

    à la figure 8 et à la figure 9. Les boulons M8 doivent être sélectionnés en fonction de la surface de montage spécifique au site Matériel et doit inclure le matériel de verrouillage. Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 43 of 52...
  • Page 44 Assurez-vous un espace libre suffisant autour des connecteurs de cloisons pour l'accès et l'entrée des câbles. 2 x M5 x 0.8, max. 10mm 4 places Figure 23: Points de montage du module TTU Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 44 of 52...
  • Page 45 Slot for pole strap 4 places M8 screw or bolt 4 places Figure 24: Montage du module TTU avec de petits supports Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 45 of 52...
  • Page 46: Installation Par Câble À La Terre

    Le système de mise à la terre Pearl Gateway doit respecter les codes électriques locaux et nationaux. Le conducteur de terre de protection terrestre terminé au niveau du point de terre Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 46 of 52...
  • Page 47 ° 8-32 avec rondelles de serrage plates et à étoile, serrées à 2,2 Nm (20 lb. lb). #8-32 Figure 26: Module de passerelle mobile Pearl Ground Point Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 47 of 52...
  • Page 48 #8-32 Figure 27: Pearl Fixed Gateway Module Ground Point Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 48 of 52...
  • Page 49: Installation Du Câble D'alimentation Cc

    à deux broches (CPC). Le connecteur CPC accouplé doit être conforme au tableau 2 et doit respecter la polarité identifiée dans la figure 14. Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 49 of 52...
  • Page 50 3 et doit suivre l'assignation de signal identifiée à la figure 15. DC Positive DC négatif Pin 5 Pin 6 Figure 30: Module de connexion fixe Signaux du connecteur d'alimentation CC Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 50 of 52...
  • Page 51 étanche et doit être enregistrée pour être utilisée à l'extérieur. TEKTELIC recommande d'enregistrer avec Scotch Wireless Weatherproofing Kit, WK-101. Suivez les procédures d'enregistrement décrites par le fournisseur de ce système de bande. Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 51 of 52...
  • Page 52 Radio Fréquence. L'étiquette IC doit être visible de l'extérieur du produit final, ou le dispositif hôte doit porter une deuxième étiquette indiquant: "Contient IC: 22504-T0004438". Pearl Gateway User Manual T0004906 Version 1.6 TEKTELIC Communications Inc. Confidential Page 52 of 52...
