Leben im Bad
Living bathrooms
L-Cube
Mounting instructions
74
45
B
E
A
900 - C - D = E
Observe the drilling dimensions!
Follow all other installation instructions!
Instructions for use
The bathroom furniture range complies with the standards and guidelines applicable at the time of delivery and is designed for use in bathrooms.
Direct contact with water should be avoided, for example, when showering.
Ceramics wider than 600 mm must be fixed to the wall.
We reserve the right to make technical improvements and design modifications to the products illustrated.
MAL_L-Cube_LC5800/16.11.1
74
45
A
mm
mm
620
382
8x 6,3x10,5
4x 74x58x40x2
C
D
F
B
8x 4x15
# LC 5800
F
mm
80
80
46
2x 100
6x S8
6x 5,5x50
D=30
D=45
mm
66
66
31
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for DURAVIT L-Cube LC 5800
Summary of Contents for DURAVIT L-Cube LC 5800
- Page 1 Leben im Bad Living bathrooms L-Cube # LC 5800 Mounting instructions D=30 D=45 900 - C - D = E 2x 100 8x 6,3x10,5 6x S8 4x 74x58x40x2 8x 4x15 6x 5,5x50 Observe the drilling dimensions! Follow all other installation instructions! Instructions for use The bathroom furniture range complies with the standards and guidelines applicable at the time of delivery and is designed for use in bathrooms.
- Page 2 8x 6,3x10,5 8x 6,3x10,5 click Ø 8 mm Ø 8 mm click 2x S8 2x 5,5x50 8x 4x15 2x click Duravit AG, Werderstr. 36, 78132 Hornberg, Germany, Phone +49 78 33 700, Fax +49 78 33 70 289, info@duravit.de, www.duravit.de MAL_L-Cube_LC5800/16.11.1...
- Page 3 # LC 5815 – # LC 5819 # LC 5830 – # LC 5834 # LC 5835 – # LC 5839 8x 4x20 Duravit AG, Werderstr. 36, 78132 Hornberg, Germany, Phone +49 78 33 700, Fax +49 78 33 70 289, info@duravit.de, www.duravit.de MAL_L-Cube/16.11.1...
