Unplug The Power Cord - Sharp Notevision XG-C40XU Operation Manual

Air Filter Maintenance
3 Clean the air filter.
Clean the dust off the air filter and cover with a
vacuum cleaner extension hose.
Replacing the bottom air filter
Unplug the power
1
cord.
4
Replace the new air filter.
Place the new air filter underneath the tabs on
the filter frame.
• Be sure the filter cover is securely installed. The power will not turn on unless it is correctly installed.
Cleaning the bottom air filters (not removable)
If dust or dirt has collected inside the air filter housing, clean the area with a vacuum cleaner extension hose.
4 Replace the filter cover.
Insert the tab on the end of the filter cover into the
filter cover opening and press the filter cover into
position.
Remove the bottom
2
filter cover.
Turn over the projector. Press the
tab and lift open the filter cover
in the direction of the arrow.
5 Replace the filter cover.
Insert the tab on the end of the filter cover into the
filter cover opening and press the filter cover into
position.
Remove the air filter.
3
Grasp the air filter between your
fingers and lift it out of the filter
cover.
Tab
Tab
Tab
E-48
