Using The Remote Control (Input Selection) - Sharp PG-M10X Operation Manual

Using the Remote Control (Input Selection)

Using the unit (continued)
After using the unit
1
Press the POWER ON/OFF button of the
remote control or the POWER ON/OFF
button of the main unit for a few seconds.
The power will turn off and the POWER indicator will
blink orange for 1 min., then the standby status will
be activated. (The cooling fan will continue to run for
a while for cooling purposes.)
Do not unplug the power cord while the indicator is
blinking.
MOUSE ON/OFF
MENU
VIDEO COMPUTER
R-CLICK/EXIT
• The POWER ON/OFF button of the remote control and
main unit will not operate until the blinking stops.
• After the standby status is activated, wait 1 min. or more
before turning the power on again. The power will not turn
on until the 1 min. interval has elapsed.
• The cooling fan will continue to run even in standby status.
2
Disconnect the power cord.
The POWER indicator will turn off.
20
POWER STA
ON/OFF
Blinks orange
(1 min.)
↓
Illuminates orange
Using the Remote Control (Input Selection)
MOUSE
VIDEO
VIDEO button
Operating from the main unit
Inputs can be selected not only by operating the remote control
but also by using the projector's INPUT SELECT button.
POWER STATUS
ON/OFF INPUT SELECT AUTO SYNC
1
Press the VIDEO button.
The video signal (VIDEO, S-VIDEO) connected to the
input terminal of this unit will be detected and
projected automatically. If a video signal is not
detected, the message NO SIGNAL will be displayed.
2
Press the COMPUTER button.
The analog RGB signal connected to the input
terminal of this unit will be detected and projected
automatically.
(Component video will be detected if the
COMPUTER input terminal is set to "YP
31).) If a video signal is not detected, the message
NO SIGNAL will be displayed.
All video signals input to this device will be detected if
"AUTO SOURCE" is set to "ON" (page 33).
3
Press the INPUT SELECT button.
The video signal (RGB or YP
connected to the input terminal of this unit will
automatically be detected and projected. If a video
signal is not detected, the message NO SIGNAL will
be displayed.
The signals are detected repeatedly in the sequence
shown below.
→ RGB/YP
S-VIDEO ← VIDEO←
When "AUTO SOURCE" is set to "ON" (see page 33), all
signals input to this unit will be detected.
ON/OFF
MENU
COMPUTER
COMPUTER button
R-CLICK/EXIT
INPUT SELECT button
VIDEO
P " (page
B R
COMPUTER
P , VIDEO, S-VIDEO)
B R
INPUT SELECT
P
B R
