Integrating the Essential Plus
terminal with your POS
The Essential Plus terminal can integrate with your PC-EFTPOS-certified POS system by the
following two methods:
• Using the serial cable (OCLR232 EFT30 Cable) which should connect to
either the COM0 or COM1 port on the bottom of the base
• Using the USB cable (USB Type B to Type A Cable) which should be connected
to the USB type B Jack of the base

4G/3G Backup

If the Point Of Sale loses internet connection, the Essential Plus terminal can fall back to 4G/3G
connection via the internal modem in the terminal. The PC EFTPOS client on the POS will need to be
configured to use the terminals 4G/3G fall back capability for 4G/3G backup to work.
6
Serial
USB
