Quick IWL255
Merchant Operator Guide
Easy loading printer
USB connector
Smart card reader
Key Functions
Power on/off
To power the terminal on/off, hold down both the [FUNC] and [CLEAR] keys at the same time. You can also press [CANCEL]
then [OK] to confirm shutdown. This must only be done when the terminal is not plugged into power as it will cause the
terminal to restart.
Terminal Power Setting – Sleep and Shutdown mode
1.
Press the [MENU] key
2. Press [2] to enter the TERMINAL menu
3. Press [1] to enter the CONFIGURE menu
4. Press [F3] to scroll to the next page
5. Press [5] for POWER SETTING
6. Current power setting is displayed
7.
Press [F1] to have terminal go into sleep mode or [F3] for shutdown. While in sleep mode, the terminal can still perform
auto settlement and TMS logon. Press any key to return the terminal to idle state.
IWL255 Terminal Features
Integrated contactless reader
Magnetic card reader
Navigation keys

Advertisement

loading

Related Manuals for CAN IWL255

Summary of Contents for CAN IWL255

  • Page 1 Power on/off To power the terminal on/off, hold down both the [FUNC] and [CLEAR] keys at the same time. You can also press [CANCEL] then [OK] to confirm shutdown. This must only be done when the terminal is not plugged into power as it will cause the terminal to restart.
  • Page 2 3. Press [1] Purchase 4. Enter the amount of the transaction and press [OK] 5. Key in the card number on the keypad and press [OK] 6. Enter the card expiry date and press [OK] Quick IWL255 Merchant Operator Guide 2 of 6...
  • Page 3 5. Press [1] for SETTLEMENT 6. Settlement report prints Note: The terminal can also be set to settle automatically every day at a particular time Cumulative Totals Cumulative Totals indicate the amount transacted through the terminal since the last Settlement Press [MENU] key 2.
  • Page 4 The account type defaults to credit. If the card being used is a debit card, the “Credit account required” exception will occur. 5. If multiple merchant function is enabled, select the required account 6. Enter the completion amount of the transaction and press [OK] Quick IWL255 Merchant Operator Guide 4 of 6...
  • Page 5 If tipping enabled, enter tip and press [OK] or to bypass just press [OK] 8. Enter the Reference number which can be found on the top of your merchant receipt. 9. Terminal will display the correct completion transaction details after processing. Press [OK] to confirm the completion transaction and to print the completion receipt.

  • Page 6: Multiple Merchant Selection

    When used daily, the terminal recharges its batteries each time it is placed ◆ on its base, or each time the traveller charger is connected. Charging is automatic. How can the battery be charged? Using the base ◆ Place the terminal on its base...
