Press the button located on top of the control base and remove the back cover (see drawing 3).

3. Unscrew the control base inflation cap (5) to reveal the air blower inflation outlet, insert one end of the

inflation hose (7) into the outlet and turn to the right to lock it (see drawing 4).

4. Unscrew the air valve cap to reveal the stem in the up position for inflation. Insert the other end of the

inflation hose (7) into the valve and turn to the right to lock it in position (see drawing 5).

Press

5. Press the button to turn on the control unit panel buttons first.

Press the button to inflate the spa tub wall for 8 to 10 minutes

until it is firm to the touch but not hard (see drawing 6).

IMPORTANT: Do not over inflate or use high pressure air

compressor to inflate.

Press the

button again to turn it off.

Replace the air valve cap back.

NOTE: The cap is designed to be screwed on and off. Never exert

force as this could cause the complete internal inflation system of the

valve to come loose. See "Spa Tub Air Valve Fastening" for valve

maintenance.

Inflate the Spa Cover Air Bladder

1. Open the inflation valve and insert the inflation hose (7) into the

valve; press to inflate until it is firm to the touch but not hard

(see drawing 7).

Disconnect the inflation hose (7) from the air blower inflation outlet

and the valve.

Replace the control base inflation cap (5) back; close and recess

the inflation valve.

NOTE: If there is a need to add some air to the spa tub wall or spa

cover air bladder after they have been setup, refer to above "Inflate the

Spa Tub Wall" and "Inflate the Spa Cover Air Bladder" sections. The cover air bladder is preinstalled inside

the spa cover. If it needs to be reinstalled, place the uninflated air bladder inside the spa cover lip before

inflating the bladder.

Deflation

For Spa Tub Wall:

1. Unscrew the cap to reveal the stem, push the stem in and turn 90

degree right to secure it in the down position (see drawing 8).

2. Once the deflation is completed, push the stem in and turn 90 degree

left to return it to the inflation position.

3. Replace the cap back.

NOTE: To deflate the spa tub for storage, see "STORAGE" section.

For Cover Air Bladder:

1. Pull valve cap out and squeeze the valve at its base until deflated.

Close and recess the valve back.
