- Page 1 PID+ Fuzzy Logic Process Controller C22/C62/C82/C83/C72/C42/R22 Quick Operation User Manual UMQOC621A September 2018 FDC_C-Series_Quick_Operation_User_Manual_UMQOC621A.doc Page 1 of 20...
-
Page 2: Display And Keys
Quick Operation Manual C22/C62/C82/C83/C72/C42/R22 1. DISPLAY AND KEYS: During power-up, the upper display will show PROG and the lower display will show the Firmware version for 6 seconds. SCROLL/ENTER KEY: This key is used to select a parameter to be viewed or adjusted. Press for the next parameter. - Page 3 5. SEL: User Select Menu PV,SV 6. CoMM: Communication Menu bASE 7. Ct: Current Transformer Input Menu 8. PRoF: Profile Menu OFS1 OFS2 OFS3 INPT UNIT INLO INHI SP1L SFtR SP1H CT 1R FILT CT 2R DISP DTMR PASS RAMP CYCR STEP RETY...
- Page 4 2.2.5 User Select Menu (SEL): Use 2.2.6 Communication Menu (CoMM): 2.2.7 Current Transformer Input Menu key to get SEL in the lower key to get CoMM in the (Ct): Use key to get Ct in the display, then use key to enter user lower display, then use key to enter lower display, then use...
-
Page 5: Parameters Description
3. PARAMETERS DESCRIPTION: Modbus Parameter Register Parameter Description Range Notation Address Set Point 1 Low: SP1L High: SP1H Set Point 2 Low: SP1L High: SP1H Set Point 3 Low: SP1L High: SP1H Set Point 4 Low: SP1L High: SP1H Set Point 5 Low: SP1L High: SP1H Set Point 6 Low: SP1L High: SP1H... - Page 6 Modbus Parameter Register Parameter Description Range Notation Address REVR: Reverse (heating) control action OUT1 Output 1 function dIRt : Direct (cooling) control action RELY: Relay output SSrd: Solid state relay drive output 4-20: 4-20mA linear current O1TY Output 1 signal type 0-20: 0-20mA linear current 0-5V: 0-5VDClinear voltage 1-5V: 1-5VDC linear voltage...
- Page 7 Modbus Parameter Register Parameter Description Range Notation Address NoNE: No alarm function dtMR: Dwell timer action dE.HI: Deviation high alarm dE.Lo: Deviation low alarm db.HI: Deviation band out of band alarm db.Lo: Deviation band in band alarm A2FN Alarm 2 function for alarm 2 output PV.HI: Process value high alarm PV.Lo: Process value low alarm H.bK: Heater break alarm...
- Page 8 Modbus Parameter Register Parameter Description Range Notation Address NoRM: Normal alarm action LtCH: Latching alarm action A4MD Alarm 4 operation mode HoLd: Hold alarm action Lt.Ho: Latching & Hold action SP.Ho: Set point holding alarm A4HY Hysteresis control of alarm 4 Low: 0.1°C High: 50.0°C(90.0°F) OFF: Alarm output OFF if sensor fails A4FT...
- Page 9 Modbus Parameter Register Parameter Description Range Notation Address NoNE: No Parameter selected dtMR: DTMR is moved to USER Menu dISP: DISP is moved to USER Menu Pb: PB is moved to USER Menu tI: TI is moved to USER Menu td: TD is moved to USER Menu o1HY: O1HY is moved to USER Menu RR: RR is moved to USER Menu...
- Page 10 C82/C83/C72/C42: NoNE: Not selected CT1: CT1 input and Remote SP CT1.2: CT1,CT2 inputs and Remote SP C62: NoNE: Not selected EI1.2: Event input 1 and Event input 2 EI.CT: Event input 1 and CT2 input CT1.2: CT1 and CT2 inputs C22: NoNE: No selected 4-20: 4-20mA retransmission output...
- Page 11 2K4: 2.4 Kbits/s baud rate 4K8: 4.8 Kbits/s baud rate 9K6: 9.6 Kbits/s baud rate 14K4: 14.4 Kbits/s baud rate BAUD Baud rate of digital communication 19K2: 19.2 Kbits/s baud rate 28K8: 28.8 Kbits/s baud rate 38K4: 38.4 Kbits/s baud rate 57K6: 57.6 Kbits/s baud rate 115K: 115.2 Kbits/s baud rate 7bIt: 7 data bits...
- Page 12 NoNE: none SP2: SP2 activated to replace SP1 rS.A1: Reset alarm 1 output rS.A2: Reset alarm 2 output rS.A3: Reset alarm 3 output rS.A4: Reset alarm 4 output rS.Ao: Reset all alarm outputs E1FN Event input 1 function CA.LH: Cancel alarm latch d.o1: Disable output 1 d.o2: Disable output 2 d.o12: Disable output 1 and 2...
-
Page 13: Wiring Diagram
161~222 For Profiler parameters description, please refer to full version user manual 4. WIRING DIAGRAM: C62 Terminal Connection C22 Terminal Connection C83 Terminal Connection C82/C42 Terminal Connection R22 Terminal Connection C72 Terminal Connection FDC_C-Series_Quick_Operation_User_Manual_UMQOC621A.doc Page 13 of 20... - Page 14 5. PROGRAMMING: 5.1 User Security: There are two parameters PASS (password) and CODE (security code) to control the data security function. CODE Value PASS Value Access Rights Any Value All parameters are changeable =1000 All parameters are changeable 1000 ≠1000 Only user menu parameters changeable =9999 All parameters are changeable...
- Page 15 5.7 Ramp: The ramping function is performed during power up as well as any time the set point is changed. Choose MINR or HRR for the RAMP setting, and the controller will perform the ramping function. The ramp rate is programmed by adjusting the RR setting. The ramping function is disabled as soon as the Failure mode, the Manual control mode, the Auto-tuning mode or the Calibration mode occur.
- Page 16 6. AUTO-TUNING: Auto-Tuning Operation Steps: 1. The system has been installed normally. 2. Don’t use zero value for PB or TI, otherwise the auto-tuning program will be disabled. The LOCK parameter should be set to NONE. 3. Set the set point to a normal operating value or a lower value if overshooting beyond the normal process value will cause damage. 4.
-
Page 17: Error Code
14. ERROR CODE: Error Display Description & Reason Corrective Action Code Symbol Check and correct setup values of OUT2, PB1, PB2, TI1, Illegal setup values used: COOL is used for OUT2 TI2 and OUT1. IF OUT2 is needed for cooling control, the when DIRT (cooling action) is used for OUT1, or ER04 controller should use PID mode (PB≠... - Page 18 Page Left Intentionally Blank FDC_C-Series_Quick_Operation_User_Manual_UMQOC621A.doc Page 18 of 20...
-
Page 19: State Of California Proposition 65 Warning
WARNING Cancer and Reproductive Harm: This warning is intended to address certain Prop 65 chemicals that may be found in Future Design Controls products. These products can expose you to chemicals including lead and lead compounds which are known to the State of California to cause cancer, birth defects or other reproductive harm. -
Page 20: Warranty
Future Design Controls C-Series products are warranted to be free from functional defects in materials and workmanship at the time the products leave Future Design Controls facilities and to conform at that time to the specifications set forth in the relevant Future Design Controls manual, sheet or sheets for a period of three years after delivery to the first purchaser for use.
