SLIK DST-3 Operating Instructions

H426

Components

Pan & Tilt Handle
Pan Handle Lock Knob
Belt for Strap
Bowl-Locking Knob
Leg Lock Lever
2-way Leg Tip
Allen Wrench
(4mm)
Caution
Soft Grip is consumption and cannot be used permanently.
Please relace is whenever ragged.
Adjustment of the Pan & Tilt Handle
Loosen the Pan Handle Lock Knob first.
Then, adjust the angle as needed and lock it.
DST-3
R
Operating Instructions
Thank you very much for choosing SLIK DST-3 Tripod.
The SLIK Corporation has designed your tripod to be a sturdy,
rugged, dependable product that will provide you with many years of
satisfactory use.
Please take a few moments to read this operating instruction carefully
before use so that you can take full advantage of many fine features on
your tripod.
Retain this operating instruction in case you might want to refer back to it.
Caution
This caution icon refers to information pertaining to important safety
procedures in preventing injuries, or damages which may occur as a
result of mishandling this product.
Prohibition
This prohibited icon refers to information pertaining to prohibited con-
tents. Please refer to instructions closely to avoid accidents.
Quick Release
Platform
Bowl Leveler
Leg Lock Angle
Adjustment Lock
Soft Grip

How to adjust the level of pan head

Adjust the level before putting the camera on
the pan head.
1) Loosen the Bowl-Locking Knob and adjust
the bubble in the level to fit into the red color
mark, while shaking the pan head.
2) Tighten the Bowl-Locking Knob.
Remarks:
This is just rough aim and recommendable to
test in advance before operating.
Pan Head
Tilting Lock Lever
Built in Level
Panning Lock Knob
Camera
Camera
Mounting Screw
Positioning Pin
Equipment that can be
used with this Tripod
Prohibition
This product has been designed
to handle equipment weighing
under 3 kgs (6 lbs 10oz). Do not
overload.
Some equipment weighing under
3 kgs (6 lbs 10oz), such as long
lenses, may not balance well due
to its weight distribution. In such
case, please use a larger tripod.
Attaching the camera to the
Quick Release Platform
Caution
Remove the Quick Release Platform turning
the Lock Lever.

Specification

Folded Length 755 mm
(29 9/12")
Maximum Height 1,510mm
(59 5/12")
Ball Base 60mm
(2 1/3")
Weight 2.85 kg
(6lbs 3oz)
Quick Release Platform
Quick Release
Lock Lever
Mounting Wing Nut

Carrying the Tripod

Prohibition
Carrying a tripod with a camera
left on can result in unexpected
accidents. We therefore, recom-
mend you to remove your camera
while carrying the tripod.
(con.→)
