Using the device
Using the device
Assembling the clip attachment
Attaching the clip to the holder.
The clip can be mounted horizontally or vertically.
The main unit may require different orientations depending on the usage environment.
Vertical
Horizontal
Insert the main unit into the holder.
<Main unit orientation>
The main unit should be oriented so that the
power button is accessible.
Fujitsu
11
