Before you commence the assembly process we recommend that you read these instructions
thoroughly beforehand to familiarise yourself with the assembly process and to also check that you have
the correct components. If for any reason you need assistance, you can find our contact details on the
final page of these instructions.
We highly recommend that any assembly is carried out on a flat, level surface if possible and that you
use another person to assist you if necessary.
Package contents
Single chair:
2 X End Frames
1 x Seat panel (4 slats)
1 x Back panel (5 slats)
70mm Coach Screws
Cover caps.
Companion seats:
2 x single chair contents plus the following...
1 x Table Top
1 x Parasol Support
Assembly Instructions
seat/single chair
Tools required
10mm socket or spanner
Broom handle or similar and spirit level for
companion seat
companion seat/single chair
1
companion
Advertisement
Table of Contents
Related Manuals for Rutland County Thistleton Companion Seat
Summary of Contents for Rutland County Thistleton Companion Seat
- Page 1 Assembly Instructions companion seat/single chair Before you commence the assembly process we recommend that you read these instructions thoroughly beforehand to familiarise yourself with the assembly process and to also check that you have the correct components. If for any reason you need assistance, you can find our contact details on the final page of these instructions.
- Page 2 companion seat/single chair Step 1 Step 2 Place the 2 seat end frames upright on a flat level Align the seat panel flush with the front edge of the surface and slot the seat panel into place as shown. end frame as shown... (It is recommend you use an assistant for this step if possible).
- Page 3 companion seat/single chair Step 5 Step 6 ...ensuring the angled batten tops are kept flush with Cover any exposed screw heads using the cover caps the angled end frame uprights as shown above, and provided. The Thistleton chair is now complete. If you fix in place using 2 of the coach screws in each side..
- Page 4 companion seat/single chair Step 9 Step 10 Secure the table top in position using 2 of the coach Now position the 2nd chair in place with its end screws. frame front edge flush with the front edge of the table top as before and secure in place with 2 more of the coach screws.
- Page 5 companion seat/single chair Step 13 Step 14 Now slide the parasol brace up the dowel..until it meets the underside of the seat end frames. Step 15 Step 16 Check the positioning at both ends of the parasol Cover any exposed screw heads using the using the brace to ensure it is identical at both ends, rotating cover caps provided.
