Rutland County The Barrowden set Assembly Instructions

Assembly Instructions
The Barrowden set
Before you commence the assembly process we recommend that you read these instructions thoroughly beforehand to
familiarise yourself with the assembly process and to also check that you have the correct components. If for any reason you
need assistance, you can find our contact details on the final page of these instructions.
We highly recommend that any assembly is carried out on a flat, level surface if possible and that you use another person to
assist you if necessary.
Please note: Whilst a single width seat is shown here, the assembly process is identical for all Barrowden seat models.
When checking your components, only the companion and combo seats will contain the table section element. Also, the
components listed are per seat so these will be doubled or tripled in quantity depending on the model you have purchased.
The assembly process shown here is for our Barrowden dining table. However, the same process applies to all of our
Barrowden table models.

Tools required:

13mm and 10mm socket or spanner, Hammer

Components

M8 Nut, bolt and 1 x M8 120mm
1 x Seat back panel 1 x Seat panel 1 x Right arm frame
washers coachscrew
(Optional) Angled (Optional) Straight
1 x Left arm frame 1 x Table top 4 x Table leg
table section(s) table section(s)
1
