CHAPTER 1. WELCOME TO THE RESOTRON
has its own distinctive waveform and modulation characteristics when
overdriven by the on-board compressor.
Before the signal from the input of the pedal hits the filter inside the
Resotron, it passes through an optical compression stage derived from
our Philosophers Tone pedal. The increased volume and punch from
the compressor can then be mixed into the audio signal using the
BLEND control without affecting the SENSITIVITY of the envelope.
The Resotron also has a TRIGGER (aka Sidechain) feature which
enables the musician to use an external audio source to modulate the
filter.
1.1

Features:

24db/oct Filter based on the SSM2040 chip
Low Pass, Band Pass & High Pass Filter options
Velocity controlled UP & DOWN envelope modes
Pitch Following envelope function with variable GLIDE
BLEND control mixes in Philosophers Tone compression
Expression pedal / 0-5V CV input modulates CUTOFF
OSCILLATE mode for monophonic synth sounds
Sidechain TRIGGER input for external audio
Hardwired True Bypass Switching
18VDC Power Supply Included
100% Analog Design
Circuit Design by Nick Cote
Sound Design by David Koltai
