Summary of Contents for Central Pneumatic 46168

  • Page 1 , 12 GAL, V -HEAD -HEAD 3 HP 3 HP , 12 GAL, V -HEAD 46168 ASSEMBLY AND OPERATING INSTRUCTIONS 3491 Mission Oaks Blvd., Camarillo, CA 93011 Visit our Web site at http://www.harborfreight.com ® Copyright © 2001 by Harbor Freight Tools .

  • Page 2: Specifications

    Always lock up tools and keep out of reach of children. Do not force tool. It will do the job better and more safely at the rate for which it was intended. Do not use inappropriate attachments in an attempt to exceed the tool capacity. SKU 46168 Page 2...
  • Page 3 18. Do not operate tool if under the influence of alcohol or drugs. Read warning labels on prescriptions to determine if your judgment or reflexes are impaired while taking drugs. If there is any doubt, do not operate the tool. SKU 46168 Page 3...

  • Page 4: Operation

    Unscrew (do not pull) the Dip Stick out. Check the level of the oil. Maximum There are two lines on the bottom of the Dip Stick. The oil Minimum level should always be at maximum. REV 02/04 SKU 46168 Page 4...
  • Page 5 Warning: Do not open the Water Spill Valve (11) so that more than four threads are showing. Push down on the On/Off Pressure Switch (3) to turn the compressor off. Unplug the electrical plug. REV 02/04 SKU 46168 Page 5...

  • Page 6: Maintenance

    REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO. NOTE: Some parts are listed and shown for illustration purposes only and are not available individually as replacement parts. SKU 46168 Page 6 REV 02/02 REV 02/04...
  • Page 7 Discharge Pipe Dip Stick On/Off Pressure Power Switch Pressure Relief Valve Handle Air Control Valve Foot Cord and Plug Pressure Gauge Water Spill Valve Wheel Air Tank Fan Guide Capacity Case Assembly Drawing No. 1 REV 02/02 SKU 46168 Page 7...
  • Page 8 Scraping Oil Ring Piston Piston Ring Crankshaft Retainer Connecting Rod Crankshaft Front Cover Gasket Crankshaft Case Stator and Case Bearing Oil Seal Armature Back Cover Screw Fan Guide Gasket Connector Capacity Case Capacity Capacity Case Cover Screw Washer SKU 46168 Page 8...
  • Page 9 Assembly Drawing No. 2 SKU 46168 Page 9...
