Stabilisers and Outriggers

Mobile towers - AGR method
Stabilisers
Attach one stabiliser to each corner of the tower as shown. Ensure
stabiliser feet are equally spaced to form a square.
SP10 and SP15 telescopic stabilisers must always be fully extended.
Position the lower clamp so that the lower arm is as close to the
horizontal as possible. Adjust the position of the top clamp to ensure
the stabiliser foot is in firm contact with the ground. Ensure clamps
are secure.
Stabilisers are used when the tower is to be moved occasionally,
frequent movement will require mobile outriggers.
When moving the tower, adjust the top clamps to lift the four stabiliser
feet a maximum of 25mm off the ground and then unlock the castor
brakes. After moving ensure all four stabiliser feet are repositioned in
firm contact with the ground.
Stabiliser dimensions
y
Outriggers
For information on mobile outriggers please consult your supplier.
bossaccesstowers.com
y
SP7 1227
SP10 2241
SP15 2757
