Quantity Schedule
850 width towers
Number of working platforms allowed
The MAXIMUM SAFE WORKING LOAD (the combined weight of
the users, tools and materials) that may be placed on the tower is
the total weight less the self-weight of the tower. The total weight
for the towers shown in the schedule is 950kg.
Example 1:
An 850 Clima tower built using the AGR method with a 4.2m
platform height and a platform length of 1.8m has a self-weight of
158kg.
950kg
-
Total Weight
Example 2:
An 850 Clima tower built using the AGR method with a 10.2m
platform height and a platform length of 2.5m has a self-weight of
348kg.
950kg
-
Total Weight
For greater heights and loads, contact us for guidance.
Platform loading
On an 850 tower a platform comprises of a single deck only. The
maximum safe working load (the combined weight of the users,
tools and materials) that may be placed on a platform is 275kg,
evenly distributed over the deck.
The quantities on page 12, will enable BoSS towers to be built
safely and therefore comply with the requirements of the Work at
Height Regulations. They include double guardrails to all platforms,
and toe boards will need to be added if any levels are used as
working platforms and for storage of materials.
EN 1004 requires platforms at least every 4.2m, and these
measures will exceed that requirement.
13
158kg
=
Self-weight
348kg
=
Self-weight
792kg maximum safe working load
(users, tools and materials)
602kg maximum safe working load
(users, tools and materials)
