Quantity Schedule
1450 width towers
Number of working platforms allowed
The MAXIMUM SAFE WORKING LOAD (the combined weight of
the users, tools and materials) that may be placed on the tower is
the total weight less the self-weight of the tower. The total weight
for the towers shown in the schedule is 950kg.
Example 1:
A 1450 Clima tower built using the AGR method with a 4.2m
platform height and a platform length of 1.8m has a self-weight of
201kg.
950kg
Total Weight
Example 2:
A 1450 Clima tower built using the AGR method with a 11.7m
platform height and a platform length of 2.5m has a self-weight of
548kg.
950kg
Total Weight
For greater heights and loads, contact us for guidance.
Platform loading
On a 1450 tower a platform may comprise of a single deck or two
decks placed side by side. The maximum safe working load (the
combined weight of the users, tools and materials) that may be
placed on a platform is 275kg. This must be evenly distributed over
either one deck, or two decks placed side by side.
The quantities on page 9 will enable BoSS towers to be built safely
and therefore comply with the requirements of the Work at Height
Regulations. They include double guardrails to all platforms, and
toe boards will need to be added if any levels are used as working
platforms and for storage of materials.
EN 1004 requires platforms at least every 4.2m, and these
measures will exceed that requirement.
bossaccesstowers.com
201kg
-
Self-weight
548kg
-
Self-weight
749kg maximum safe working load
=
(users, tools and materials)
402kg maximum safe working load
=
(users, tools and materials)
