Quantity Schedule
1450 width towers
Ballast: Internal/external use
There is no requirement for ballast on 1450 towers if using
stabilisers as detailed in the table on page 9.
Mobile Outriggers
MP16 outriggers can be used instead of SP15 stabilisers, as
detailed below. Mobile outrigger kits comprise:
Mobile outrigger kit
MP16 Mobile Outrigger
125/150/200mm Castor
(Use same diameter castors as on
tower)
250mm Adjustable leg
Plan Braces
The above components replace:
SP15 Stabiliser
Stabilisers
To improve rigidity, larger stabilisers can be used at a lower level
than shown in the table on page 9.
Angle of Stabiliser 1450 Tower
X
90°
Double width 1450 Towers Dimension X
SP7
SP10
SP15
11
X
Platform length
1.8m
X= 3351
X= 4789
X= 5520
4
4
4
4
4
Platform length
2.5m
X= 3629
X= 5100
X= 5838
